Electroflo® Contemporary™ Tap
Verified by manufacturer 4 months ago
Polished Chrome Battery – 323680
Polished Chrome Battery – 323680
Automatic washbasin tap.
Application
For vanity-top or washbasin mounting, suitable for use in most domestic and commercial applications.
Description
The Dudley Electroflo® Contemporary™ Tap is a vanity top/basin mounted electronic tap. Suitable for use in most domestic and commercial applications with a contemporary design.
Features and benefits:
- Stylish tubular design.
- Hygienic touch-free operation.
- Robust brass body and vandal resistant design.
- Attractive chrome plated, stainless steel effect or black finishes are available.
- Delivers cold or premixed warm water.
- Shuts off when hand is removed from in front of sensor.
- Must be installed with a thermostatic mixing valve for premixed water.
- Shuts off when hand is removed from in front of the sensor.
- Adjustable water delivery, set to automatically stop after 90 seconds.
- Pre-fitted with 5 L/minute flow regulator.
- ½” BSP connection.
- Suitable for pressures of 0.5–8.0 bar, 8.0+ with a flow restrictor.
- 80–300 mm sensor range.
- Maximum temperature 70°.
- Fail safe feature automatically closes the solenoid when power is cut or power is very low.
- Supports BREEAM.
General information
Color | Black Silver |
Finish | Matt Chrome Stainless steel |
Material | Brass |
Shape | Other |
Length | 132 mm |
Height | 142 mm |
Warranty description | One year |
Uniclass | |
CAWS | N13/341 Vanity tops with formed washbasins N13/335 Washbasins N13/30 Washbasins |
Specification data - Washbasin taps
Form | Automatic-action cold tap.Automatic-action thermostatic mixer tap.Guidance for specification option: Thermostatic mixer valve required for premixed water. |
Materials | |
Body | Brass. |
Finish and colour | Chrome-plated. |
Flow rate (maximum) | 6 L/minute at 8 bar.Guidance for specification option: Water pressure: 0.5–8.0 bar. To achieve above 8.0 bar install with a flow restrictor. |
Water supply temperature (maximum) | 70°C. |
Integral accessories | Occupancy detectors. |
Power supply | Battery, 9 V PP3. |
Operating voltage | 9 V DC. |
Water pressure | 0.5–8.0 bar. |
Sensor | Infra-red sensor, 80–300 mm range (pre-set to 220 mm). |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Brass |
Recyclability | Yes |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
