Verified by manufacturer 2 months ago
Ekotex 10 (1300)
Needle punched, non-woven geotextile.
Function:
Application:
Ecotex® geotextiles are a range of polypropylene, staple fibre, needle punched non-woven geotextiles. The fibres are needled to form a stable network that retains dimensional stability relative to each other.
Features and benefits:
Color | White |
Finish | Unfinished |
Material | Polypropylene |
Shape | Other |
Length | 100000 mm 80000 mm 40000 mm 50000 mm |
Width | 4500 mm 2200 mm 5500 mm 2750 mm |
Height | 0.61 mm 0.82 mm 1 mm 1.15 mm 1.2 mm |
Warranty description | 120 year |
Uniclass | |
CAWS | D20/58 Geotextile sheet D20/550 Geotextile sheet |
Material | Polypropylene. |
Purpose | Geotextile. |
Standard | To EN ISO 10319. |
Performance characteristics | |
Tensile strength (minimum) | 11 kN/m (MD); 11 kN/m (CD). |
Elongation to break | 50% (MD); 60% (CD). |
Form | Micro-perforated (needle-punched). |
Physical properties | |
Colour | White. |
Weight (minimum) | 77 kg. Guidance for specification option:
33 kg. Guidance for specification option:
Manufacturer guidanceRoll weight excluding core. |
Dimensions | |
Thickness (minimum) | 1 mm. Manufacturer guidanceThickness under 2 kPa (mm), to EN ISO 9863 -1. |
Width (minimum) | 2.2 m. 5.5 m. |
Roll length (minimum) | 100 m. |
Diameter | 380 mm. Manufacturer guidanceRoll diameter. |
Flow rate | To EN ISO 11058, 70 L/m²s. Manufacturer guidanceWater flow rate. |
Puncture resistance | To EN ISO 12236, 1800 N. Manufacturer guidanceResistance to Static Puncture (CBR). |
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | Fully Recycable |
