Rhyno - Woven Polypropylene Geotextile - Woven Polypropylene Geotextiles
Verified by manufacturer 3 months ago
Rhyno GW609
Rhyno GW609
Woven civil engineering geotextile.
Application
Suitable for use in a wide range of civil engineering applications, including:
- Reinforcement.
- Stabilisation.
- Separation.
- Drainage.
Application:
- Roadways.
- Car parks.
- Haulage yard.
- Working platforms.
- Explosive demolition blast wrap.
Description
A range of polypropylene woven geotextiles.
Features and benefits:
- Resistant to ultraviolet degradation and to biological and chemical environments normally found in soils.
- Reduces maintenance costs.
- Advanced weaving technology.
- Strong, robust and durable.
- Combines high tensile strength with exceptional puncture resistance to give outstanding performance and longevity.
- Resistance to all naturally occurring soil acids and alkalis.
- Reduces the degradation of any surface that relies on an aggregate sub base by distributing loads more evenly and reducing rutting.
- CE marked to comply with the latest European standards.
General information
Color | Black |
Finish | Woven |
Material | Polypropylene |
Shape | Other |
Length | 100000 mm |
Width | 4500 mm 2500 mm 5250 mm |
Warranty description | 120 year |
Uniclass | |
CAWS | Q25/64 Geotextile sheet D20/58 Geotextile sheet Q25/365 Geotextile sheet D20/550 Geotextile sheet |
Specification data - Plastics sheets
Material | Polypropylene. |
Purpose | Geomembrane. |
Standard | To EN ISO 10319. |
Performance characteristics | |
Tensile strength (minimum) | 16 kN/m (MD); 11 kN/m (CD). |
Elongation to break | 20% (MD); 19% (CD). |
Form | Woven. |
Physical properties | |
Colour | Black. |
Weight (minimum) | 40 kg.Guidance for specification option: 4.5 x 100 m roll. 9 kg.Guidance for specification option: 2.25 x 50 m roll. 5 kg.Guidance for specification option: 4.5 x 11.1 m folded pack. |
Dimensions | |
Width (minimum) | 4.5 m.2.25 m. |
Roll length (minimum) | 100 m.Guidance for specification option: 4.5 x 100 m roll. 50 m.Guidance for specification option: 2.25 x 50 m roll. 11.1 m.Guidance for specification option: 4.5 x 11.1 m folded pack. |
Diameter | 160 mm. 145 mm. Folded pack. Manufacturer guidanceRoll diameter. |
Flow rate | To EN ISO 11058, 15 L/m²s. Manufacturer guidanceWater flow rate. |
Puncture resistance | To EN ISO 12236, 1500 N. Manufacturer guidanceResistance to Static Puncture (CBR). |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | Fully Recycable |
Literature
Rhyno® Woven Polypropylene Geotextiles - Data Sheet
Case studies
Case Studies
