EBD 44 Riser

Verified by manufacturer 5 months ago

Single door - Non Fire Rated

EBD Steel Doors (formerly Eurobond Doors) Variant:
Third party certifications:
  • Certifire Certificate

    Certifire Certificate

    Certificate type

Fire rated steel riser doorsets (FD60/120/240(s)).

Jump to:
+44 (0)2920 36 11 11 Website

Application

Suitable for commercial applications.

Description

Fire-resisting metal doorsets for service cupboards, service risers and other non-personnel secondary rooms. The steel riser door provides the containment and fire performance required by these areas of the building.


Features and benefits:

  • Provides fire resistance of up to 240 minutes.
  • Double and single doorsets are available.
  • Available with a range of frame and louvre options.

General information

Color

Other

Guidance for specification option:

Available in the standard RAL colour range.

Finish

Powder-coated

Material

Steel

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

One year

Uniclass

Pr_30_59_24_52 Carbon steel doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

Specification data - Carbon steel doorsets

Configuration

Single leaf, left hand opening.

Single leaf, right handed opening.

Doorset size

Guidance for specification option:

  • Refer to data sheet for sizes.
  • Insert requirements or refer to a schedule.

Performance

-

Fire resistance

-

Integrity

Not required.

Smoke leakage

Not required.

To EN 1634-3:2004, Sa.

Acoustic performance

Not required.

To BS EN ISO 10140-2, sound reduction index Rw 32 dB.

Thermal

2.1 W/m²K.

Frame

-

Material

1.2 mm galvanized steel.

Threshold

EBD standard threshold.

Drop seal.

Aluminum threshold.

Without threshold.

Raindrip threshold.

Perimeter seals or inserts

Teardrop self adhesive silicon cold smoke seal pre-fitted to the internal rebate of the frame to BS 476-31.1 and EN 1634-3.

Manufacturer guidance

Gasket.

Finish

-

Coating

Powder-coated.

Texture

30% gloss (matt).

Colour

RAL colour range.

Guidance for specification option:

Standard RAL colour range, paint finish 30% gloss (matt) minimum 40 microns. Insert requirements.

Door leaf

-

Thickness

44 mm.

Core

Dufaylite corrugated cardboard.

Material

1.2 mm galvanized steel interlocked to the back face and fixed on the top and bottom edge of the door blade.

Finish

-

Coating

Powder-coated.

Texture

30% gloss (matt).

External colour

RAL colour range.

Manufacturer guidance

Standard RAL colour range, paint finish 30% gloss (matt). Insert requirements.

Internal colour

RAL colour range.

Manufacturer guidance

Standard RAL colour range, paint finish 30% gloss (matt). Insert requirements.

Film thickness (minimum)

40 micrometres.

Door accessories

Not required.

Kickplates - stainless steel brush finish.

Guidance for specification option:

Standard height 200 mm (up to 1250 mm from FFL, other heights available to order).

Kickplates - aluminium chequer plate.

Guidance for specification option:

Standard height 1250 mm from FFL.

Hardware

Pull handle - Deadlocking.

Lever handle - Nightlatch.

Door frame profile

Fixed rebate frame.

Guidance for specification option:

Frame width: 96 mm.

Applications:

  • Blockwork and masonry walls.
  • Reinforced concrete walls.

Architrave frame.

Guidance for specification option:

Frame width: Wall thickness + 30 mm.

Applications:

  • Plasterboard steel stud partitions.
  • White wall sandwich panels. Please contact manufacturer to verify approved systems.

Clamp frame.

Guidance for specification option:

Frame width: Wall thickness + 7 mm.

Applications:

  • White wall sandwich panels. Please contact manufacturer to verify approved systems.

Meeting stiles

Single astragal.

Plain.

Louvres

AFDL.44 Anemostat metal louvre - double 457 x 457 mm.

AFDL.44 Anemostat metal louvre - lower 457 x 457 mm.

AFDL.44 Anemostat metal louvre - upper 457 x 457 mm.

AFDL.44 Anemostat metal louvre - large 457 x 1546 mm.

Hinges

Grade 14 concealed bearing hinge - EN 1935:2002 and CE marked.

Guidance for specification option:

Satin stainless steel finish.

Door closer

EN 1154, CE or UKCA marked.

Guidance for specification option:

Cam Motion or Rack and Pinion.

Sustainability data

Country of product manufacture

United Kingdom

Recyclability

100

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

35 %

BIM objects

Platform Compatible Version
Revit
-

1

Third party certifications

Certifire Certificate

CF6007 - Internal HD Uninsulated Steel Fire Doorset

Certifire Certificate

CF 5960 - Internal MD Uninsulated Steel Fire Doorset
