E100 Rimfree Square btw
Application

Available for use in:

  • Commercial and residential areas.
  • Hotels.

Description

Rimfree back-to-wall WC with concealed cistern and horizontal outlet.

Features and benefits:

  • Environmentally friendly.
  • Square design.
  • Soft closing mechanism.
  • Easy to clean due to rimless design.
  • Concealed cistern.

Applications:

Available for use in:

  • Commercial and residential areas.
  • Hotels.

General information

Material

Vitreous china

Uniclass 2015

Pr_40_20_93_97 WC suitesPrimary

CAWS

N13/10 WC pans and flushing arrangements

N13/300 WCs and cisterns

Specification data - WC suites

Product Reference

E100 Rimfree Square btw

Pan

E11588WH

Rimfree horizontal outlet.

Cistern

Insert requirements from the Twyford concealed cisterns matrix.

Seat and cover

E17856WH

Metal hinges, soft closing mechanism.

E17858WH

Metal hinges, quick release, soft closing mechanism, square.

E17866WH

Metal hinges, top fix.

WC Outlet Connector

WF1240WH

P trap outlet connector.

WF1241WH

S or turned P trap connector.

Standard product features

Size (l x h x w):

530 x 355 x 400 mm.

Material:

Vitreous china.

Colour:

White WH.

Fixings:

Screwed to floor with fixings provided, seal to wall and floor using silicone building sealant (not provided).
