DuPont™ AirGuard® Control
Verified by manufacturer 2 months ago
Airtight vapour control layer.
Application
Suitable for roofs, walls or floors.
Description
A dedicated air barrier with 100% airtightness and low vapour resistance, which allows rapid drying-out of damp wall elements. The primary function is to improve energy-efficiency by reducing convective heat losses through a roof, wall or floor element.
Features and benefits:
- Limited vapour transmission.
- Airtight and water resistant.
- CE-conformity for plastic and rubber vapour control layer (EN 13984).
- Superior mechanical strength.
- Reaction to fire: Class E.
- Lightweight and easy to install.
- Reduces convective heat losses and vapour transfer.
- Reduces risk of trapped moisture in the insulation.
General information
Color | Blue |
Finish | Smooth |
Material | Polypropylene |
Shape | Other Guidance for specification option: Roll. |
Length | 50000 mm |
Width | 1500 mm |
Height | 0.32 mm |
Warranty description | 25 year |
Uniclass | |
CAWS | H20/10 Sheet cladding H20/150 Sheet cladding (attached to metal support systems) H20/155 Sheet cladding (attached to timber battens) H21/115 Vertical timber weatherboarding H30/10 Fibre cement H30/110 Fibre cement H30/120 Fibre cement H30/261 Air and vapour control membrane H30/30 Air and vapour control membrane H31/10 Metal H31/110 Metal H31/120 Metal H31/261 Air and vapour control membrane H31/45 Air and vapour control membrane H40/110 GRC cladding H40/230 Air barrier H51/110 Cladding K10/155 Wall lining system (metal studs) K21/10 Wood laminate flooring K21/110 Wood flooring K21/115 Wood laminate flooring K21/120 Battened wood flooring K21/130 Battened wood floating floor K21/140 Battened wood laminate flooring K21/145 Composite laminate flooring K21/146 Laminate flooring K21/150 Wood lining K21/160 Wood lining on battens M30/265 Building paper P10/240 Insulation fitted between floor joists P10/310 Air and vapour control layer P10/60 Air and vapour control layer |
Specification data - Plastics sheets
Material | Polypropylene.Ethylen-butylacrylate Co-polymer. |
Purpose | Vapour control layer. |
Standard | To BS EN 13859-2. |
Performance characteristics | |
Tensile strength (minimum) | 170 N/50 mm. |
Tear resistance | 240 N. |
Elongation to break | 38%. |
Water vapour resistance (minimum) | 26 MN·s/g. |
Fire performance | To EN 13501-1, Class E. |
Third-party certification | British Board of Agrément (BBA) Certificate. |
Form | Spun-bonded. |
Physical properties | |
Colour | Blue. |
Weight (minimum) | 108 g/m². |
Dimensions | |
Thickness (minimum) | 0.25 mm. |
Width (minimum) | 1.5 m. |
Roll length (minimum) | 50 m. |
Accessories | Tyvek® 2060B Tape. Guidance for specification option: Single sided tape for sealing overlaps in Tyvek® membranes and making good around penetrations, pipework, windows and door openings. Very durable ensuring long term performance. Roll size: 75mm x 25m. Tyvek® Double Sided Acrylic Tape. Guidance for specification option: Double sided acrylic tape for sealing laps in Tyvek® membrane and bonding to smooth surfaces. Excellent adhesion properties under extreme conditions. Strong initial tack. Roll size: 50mm x 25m. Tyvek® Butyl Tape. Guidance for specification option: Double sided butyl based sealant, used to seal fixing penetrations in a Tyvek® membrane and form a moisture and airtight seal between a Tyvek® membrane and most commonly used building materials. Tape is compatible with brickwork, blockwork, masonry, timber, metalwork and most plastic products. Roll sizes: 20mm x 30m, 50mm x 30m. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 6 |
 Revit | - | 7 |
Literature
Tyvek Technical Wall Manual 2022
Tyvek Technical Roof Guide 2022
