DuoLift® Joist Pedestal

Application

Suitable for roof terraces and ground-level terraces, the DuoLift Joist Supports require a substrate that is solid, stable and structural (not directly onto soil).

Description

Versatile and user-friendly subframe support system.

Providing substantial height flexibility within four stackable components, DuoLift® removes the common problem of having to order varying height pedestals for a single area. Height-adjustable from 15 mm, DuoLift™ makes accurate height-setting easy.


Features and benefits:

  • The Joist Cradle features 5 mm height measurement markings on the side, making installation easier,
  • Turning the adjustment ring around the cradle ¼ of a turn results in 1 mm of height adjustment.
  • Key-locking tabs hold the joist in place.
  • Self-levelling from 35 mm upwards.
  • Lugs on the outside make it clear to identify when the system is locked together.
  • Acoustic separation pad protect membranes, as well as reducing noise transfer.
  • Works with DuoSpan, aluminium, plastic and timber joists, for joist widths up to 69 mm.
  • Resistant to moulds, algae, alkali, bitumen, UV.


Components:

  • DuoLift Joist Cradle, 15–60 mm.
  • DuoLift Self-Levelling Joint, 20 mm.
  • DuoLift Riser, 45 mm.
  • DuoLift Foot, 45 mm.
  • DuoLift Acoustic Separation Pad, 3 mm.

General information

Color

Black

Material

Nylon

30% Glass Filled Nylon.

Shape

Circle

Size

Adjustable from 15 mm up to 350 mm.

Uniclass 2015

Pr_20_85_47_22 Decking and paving pedestalsPrimary

CAWS

Q55/110 Deck

Q55/395 Support pedestals

Specification data - Decking and paving pedestals Enhanced data

Pedestal type

Adjustable.

Material

30% Glass Filled Nylon 6.

100% recycled.

Adjustment

15—350 mm.

Accessories

DuoLift Acoustic Separation Pads.

When installing over a waterproofing membrane.

Execution

Installing decking and paving pedestals.

Diameter

114 mm.

DuoLift joist cradle, self-levelling joint and riser diameter.

220 mm.

DuoLift Foot diameter.

Working temperature

-30 to +120°C.

Flammability

L94 Class HB.

Capacity

Loading Capacity.

5 kN.

DuoSpan Joists.

3.7 kN.

Plas-Pro or Timber Joists.

Safety

1.3—1.9.

Intermediate support spacing

Spacing depends on the limits of the subframe used, consult subframe manufacturer for more details.

-

Environmental information

Recyclability

100%

Recycled content

100

Digital objects

Platform Compatible Version Certified to
Revit
-

1

2.1
IFC
-

1

2.1
Download now from NBS National BIM Library
