Dulok 25 - Fencing system - Security fence

Name: Dulok 25 - Fencing system - Security fence
Brand: CLD Physical Security Systems
SKU: aE5tTJ5kjj8bmmYx3LoL7L

NBS BIM object standard

Verified by manufacturer over a year ago

CLD Physical Security Systems

Double wire weldmesh rigid mesh panel fencing system.

Jump to:

+44 (0)1270 764751 Website

Application

Industrial and commercial buildings.

Public buildings.

Schools.

Police stations and secure units.

Description

The Dulok-25™ double wire panel system can be used in applications such as data centres, secure units, MOD sites and police stations. With its twin 8 mm wire configuration and 25 mm spaced 6 mm vertical wires, this one of the most impenetrable fence systems on the market. Available in heights ranging from 1200–6000 mm.

Features:

Extremely high security, anti cut-through, double wire panels.
Wide range of height options (up to 6 m).
RAL colours available.

Standards:

Conforms to BS 1722-14.

General information

Finish	Powder-coated Galvanized
Material	Steel
WarrantyDescription	15 year

Uniclass	Ss_25_14_67_51 Metal mesh panel fencing systemsPrimary
CAWS	Q40/126 Open mesh steel panel security fencing Q40/27 Open mesh steel panel general purpose fencing Q40/30 Proprietary fencing Q40/430 Proprietary fencing

Specification data - Metal mesh panel fencing systems

System performance	Anti-intruder and security fencing performance.
Standard	To BS 1722-14.
Posts In addition to the standard posts, many variations are available to accommodate site requirements: Wall fixing plates, cranked posts or base plated. Cranked or straight extensions for barbed or razor wire. Cranked panels.	Manufacturer's standard Purpose-made Insert requirements.
Fence topping	Not required. Barbed wire. Double mesh cranks. Razor wire, coiled.

Panel height: Fence heights above 2430 mm are made up of two or more panels.	1830 mm. 2030 mm. 2430 mm. 3060 mm. 4060 mm. 4460 mm. 5090 mm. 5490 mm. 6090 mm. Show more
Colour and finish	Galvanized and polyester powder-coated, RAL. RAL 6005 as standard, full spectrum of colours available subject to quantity and price.
Fixing	Pin hex. Sheardrive.
Width	2506 mm.
Mesh size	200 x 25 mm.
Top edge protection	30 mm. Can be inverted to give flush edge.
Product Reference	Dulok-25™
