NBS Source

Application

Suitable for public washrooms.

Description

Features and benefits:

  • Can be supplied as a pre-built frame.
  • Alternatively, timbers are prepared ready to receive the plywood skirting and header rail.

General information

Color

Available in any RAL colour.

-

Finish

Various options available.

Lacquered

Material

Medium density fibreboard (MDF)

18 mm moisture resistant MDF, factory sprayed finish to any RAL colour.

WarrantyDescription

From practical completion

One year

Uniclass

Ss_25_25_45_25 Duct and wall panel lining systemsPrimary

CAWS

K32/140 Duct/ wall linings – panels only

Specification data - Duct and wall panel lining systems

Panels

Depends on specification of sanitaryware.

Fasteners

Supplied complete with corresponding flashgap laminate and Hafele push on/ lift off brackets.

Supporting frame

-

Duct panels

Assembled frames constructed from 60 x 40 mm treated softwood complete with plywood skirting and header.

Wall panels

Assembled frames constructed from 60 x 40 mm treated softwood complete with plywood skirting and header.

Flash gap panels

1 mm HPL flashgap bonded to framework.

Edge treatment

Lipped with corresponding PVC, lipped with matching laminate.

Edge to match face.

Colour

To be confirmed from WW standard range.

-

Environmental information

Country of material origin

United Kingdom

Digital objects

Platform Compatible Version Certified to
IFC

IFC2X3

2

1.3
Revit

Revit 2016

3

2.0
Download now from NBS National BIM Library
