Dream™ DCV Bath/ Shower Mixer

Suitable for household showering areas.


Dual control valve bath filler/ shower mixer with adjustable shower head.

Features and benefits:

  • Sleek, striking design.
  • Versatile.
  • Excellent performance.
  • Slimline concealed valve.
  • Includes a temperature override button for extra safety.
  • Shower heads include easy clean nozzles to help reduce limescale build-up.
  • Anti-twist hose connector.
  • Adjustable rail fitting.
  • Harmony™ head with a choice of four spray patterns (inner, middle, outer, and eco).
  • The ‘Eco’ spray setting saves up to 25% water without compromising performance.
  • Separate flow and temperature control.
  • Suits high pressure, combination boiler and boosted gravity water systems.
  • Five-year guarantee.
  • Matching shower-only models available (specified separately).


Suitable for household showering areas.

General information



Uniclass 2015

Pr_40_20_87_07 Bath mixer taps with shower hose and hand spraysPrimary


N13/35 Baths

N13/355 Baths

Specification data - Bath mixer taps with shower hose and hand sprays

Product Reference

Dream™ DCV - DRMDCV004

Dual outlet mixer shower with adjustable head and bath overflow filler.

Standard product features



Shower head:

105 mm diameter Harmony™ head with four spray patterns.

Control plate size (h x w x d):

200 x 140 x 50–65 mm. Includes 25 mm levers which can be inserted if required.


  • Inlet centres: 140 mm.
  • Inlet fitting connections: 3/4" BSP female inlet connections (suitable fittings required).
  • Inlet supply positions: Hot/ left, cold/ right.
  • Outlet connections: 3/4" BSP female connections (suitable fittings required).

Rail length:

865 mm.

Hose length:

1.5 m.

Bath overflow filler:

70 mm diameter with 25 mm depth, includes clicker waste fitting. 1/2" BSP female inlet fitting (15 mm push fit house included).

Pressure requirements:

1–5 bar (static).

Supply temperature:

  • Cold: 5–20°C.
  • Hot: 55–65°C.
