Drawer Runner - Pull Out Lock Shelf - Shelf Solution

Blum UK Third party certifications:
  • ISO 14001:2015

    ISO 14001:2015

    Certificate type

  • ISO 9001:2015

    ISO 9001:2015

    Certificate type

  • FSC

    FSC

    Certificate type

Pull-out shelf lock for MOVENTO and TANDEM.

Jump to:
+44 (0)1908 285700 Website

Application

Can be used with the runners

  • MOVENTO
  • TANDEM (full extension)


Description

Blum lock-open stop for pull-out shelves with MOVENTO and TANDEM full extensions. Made in Austria. For narrow and wide pull-out shelves. Up to maximum cabinet width 1200 mm. Sleek and space-saving within the furniture. Holds pull-out shelves securely when the shelf is fully extended. The locking mechanism engages on both sides. Can be released with one hand by slightly lifting up the locking lever thanks to synchronisation. Can be combined with BLUMOTION, TIP-ON BLUMOTION and TIP-ON motion technologies.


Features and benefits:

  • Compatible for use with MOVENTO and TANDEM full extensions
  • Can be combined with BLUMOTION, TIP-ON BLUMOTION and TIP-ON
  • Sleek look and space-saving construction
  • Two-sided locking mechanism and secure hold
  • Pull-out shelf lock can be released with one hand thanks to synchronisation
  • Also suitable for installation in a compartment as a “hidden” pull-out shelf
  • Maximum cabinet width 1200 mm.



General information

Color

Grey

Finish

Matt

Material

Nylon

Shape

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

WarrantyDescription

Lifetime

Uniclass

Pr_30_36_36_24 Drawer runnersPrimary

CAWS

N10/135 Storage and display units

N10/110 Purpose-made

N10/10 Purpose-made

Specification data - Drawer runners

Form

Pull-out shelf lock side panel thickness F 19 mm.

Pull-out shelf lock side panel thickness H 16 mm.

Material and finish

Nylon.

Colour

Orion grey matt.

Literature

Pull-out shelf lock Brochure

Pull-out shelf lock Brochure

Pull-out shelf lock Specification Text

Pull-out shelf lock Specification Text

Pull-out shelf lock DIM-Certificate

Pull-out shelf lock DIM-Certificate

Case studies

A versatile shelf with a secure hold

A versatile shelf with a secure hold

Third party certifications

ISO 14001:2015

ISO 14001:2015

Blum ISO 14001 2015

ISO 9001:2015

ISO 9001:2015

Blum ISO 9001 2015

FSC

FSC

Blum FSC Certification
