Downtown Small Pillar Tap
Verified by manufacturer 7 days ago
DT.SPT.CH
DT.SPT.CH
QA Certificate
Certificate type
WRAS
Certificate type
Aqualisa Downtown chrome and matt black pillar tap small.
Application
Mixer tap.
Description
The small Downtown Basin Mixer Tap offers a compact, high-performance basin tap option in a stylish and contemporary design. The single soft squared paddle lever allows you to find your desired temperature with ease, and this bathroom sink tap comes complete with an aerator for softer, non-splash flow and a metal click-clack plug. Suitable for low- and high-pressure water systems, Aqualisa Downtown taps feature a solid brass body with durable zinc handles offering a contemporary look within the bathroom.
Features and benefits:
- Suitable for both low and high pressure systems.
- Click-clack waste included.
- Soft square design.
- Brass body with zinc handles.
Water system compatibility:
- Gravity.
- Boosted gravity.
- Combi.
- Balanced high pressure water systems.
General information
Color | Silver Black |
Finish | Chrome Matt Gloss |
Material | Brass Zinc Plastic |
Shape | Square |
Length | 137 mm |
Width | 50 mm |
Height | 130 mm |
WarrantyDescription | Five year if the product is registered |
Uniclass | |
CAWS | N13/335 Washbasins N13/30 Washbasins |
Product range |
Specification data - Mixer taps
Approvals | Water Regulations Advisory Scheme (WRAS)-approved. |
Form | Basin mixer tap. |
Materials | - |
Body | Brass, zinc, chrome plated, plastic. |
Finish and colour | Chrome-plated. |
Flow rate (maximum) | At 5 bar: 5.3 L/m (full hot), 5.2 L/m (full cold), 5.4 L/m (mixed). |
Water supply temperature (maximum) | 5–65°C. |
Integral accessories | Click-clack waste. |
Handle type | Lever, dual control. |
InletConnectionSize | 2 x braided hose with 1/2" BSP female. |
Pressure | 0.2–5 bar (static). |
MountingType | Deck mounted. |
Tap holes | One hole. |
ValveOperation | Pull, push. |
Dimensions | 130 x 137 x 50 mm. |
Weight | 1.21 kg.
|
Environmental information
Contains Red List materials | No |
Country of material origin | China |
Country of product manufacture | China |
Recycled content | % Packaging recycled content:
|
BIM objects
NBS BIM object standard
This BIM object has been authored to meet the requirements of the NBS BIM object standard.
Find out more about the NBS BIM object standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
WRAS
DT.LPT.MB & DT.SPT.MB Approval Certificate - 2010110
Additional certifications:
- BEAB Approval Mark
Literature
Aqualisa Taps Brochure
DT.SPT.CH_Spec Sheet
Aqualisa Taps Installation and User Guide
DT.SPT.MB_Spec Sheet
