Domestic Drain
Verified by manufacturer 23 days ago
110.300.050
110.300.050
Shower drains for housing and commercial applications.
Application
For all floor types in:
- Private housing bathrooms.
- Swimming pools.
- Plant rooms.
- Laundry rooms.
- Toilets and showers in hotels, hospitals and fitness centres.
Description
Square or circular shower drains for domestic tiled, vinyl and concrete floors. Available with optional removable water trap and filter basket.
Features and benefits:
- Square frame for resin, tiled and concrete flooring, or round frame for vinyl flooring.
- Vertical or horizontal 50, 75 or 110 mm diameter outlet.
- Suitable for floors with a liquid waterproofing membrane, sheet waterproofing membrane or no waterproofing membrane.
- Designed in accordance with BS EN 1253.
- Flow capacities up to 1.8 L/s.
- Brushed grain finish 8 mm holes, standard pattern.
- Low frame height.
- Trap and filter basket are removable for cleaning and maintenance.
- Grate with star lock screw-system, available in three shapes and six designs.
- Manufactured from stainless steel grade 1.4301 (AISI 304) as standard, 1.4404 (AISI 316L) is also available.
General information
Color | Silver |
Finish | Brushed Grained |
Material | Steel Stainless steel |
Shape | Square Guidance for specification option: 145 x 145 mm frame diameter (for tiled, concrete and resin flooring). Circle Guidance for specification option: 155 mm diameter (for vinyl flooring). |
Length | 145 mm 155 mm |
Width | 145 mm 155 mm |
Uniclass | |
CAWS | R11/315 Floor drains R11/5 Floor drains |
Specification data - Floor gullies
Body | |
Configuration | Guidance for specification option:
|
Material | Stainless steel grade 1.4301 (AISI 304).Guidance for specification option: Standard. Stainless steel grade 1.4404 (AISI 316L).Guidance for specification option: To specify, insert suffix S to the part number, e.g. 110.300.050 S. Consult manufacturer for details. |
Cover or grating | |
Cover or grating type | Guidance for specification option: VIENNA grating is included as standard. Other grating is available to order. Consult manufacturer for details. Manufacturer guidanceConsult manufacturer's literature and insert product reference code for alternative gratings. |
Finish | Guidance for specification option:
|
Outlet | Horizontal two-part adjustable. |
Integral accessories | Not required.502.000.000 S.Guidance for specification option: Filter basket; material: stainless steel grade 1.4404 (AISI 316L). 502.050.110 S.Guidance for specification option: Removable two-part water trap. |
Side inlets | Not required. 32 mm diameter. 40 mm diameter. |
UsePurpose | For tiled, concrete and resin flooring. |
OutletDiameter | 50 mm. |
Drain | Adjustable square shower drain. |
Dimensions | 145 x 145 mm. Guidance for specification option: Frame. |
Sustainability data
Country of product manufacture | Denmark |
