Deko Doors - DG Glazed - GD

Verified by manufacturer 1 month ago

Deko Doors Double - DG Glazed - GD

Indeglås Variant:

Double glazed doors - available and supplied using toughened glass which closes tight to the rubber profiles in the frame, providing a soundproof connection.

Jump to:
BOS
+44 (0)1236 453000 Website

Application

DEKO have developed an aluminium snap-on architrave profile. This is clipped onto the frame, providing an attractive joint detail with no visible fixings.

Alternatively, a DEKO Door can be finished with conventional timber architraves or joint filler can be used between the partition and door frame.

Description

Double glazed doors - available and supplied using toughened glass which closes tight to the rubber profiles in the frame, providing a soundproof connection.


Features and benefits:

  • Fully glazed doors are available and supplied using toughened glass which closes tight to the rubber profiles in the frame, providing a soundproof connection.
  • In the standard format Deko Doors can be delivered with approval and certification according to the Danish Standard with fire classifications up to BD60 and sound classifications up to 35 dB.
  • All doors are prefabricated, which eliminates any need for site finishing after installation. All Deko Doors have been awarded the Danish Indoor Climate Labelling.

General information

Color

White

Finish

Glazed

Material

Glass

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_30_59_23_32 Frameless glass door leavesPrimary

CAWS

L20/460 Frameless glass doors

Specification data - Frameless glass door leaves

Format

Double leaf, single action.

Leaf

-

Material

Toughened glass.

Hardware

-

Door rails and patch fittings

-

Type

Hinged.

Material and finish

Polished stainless steel.

FireRating

Up to BD 60.

Sound insulation

26—35 dB.

Third-party certification

Danish Indoor Climate Label.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Recyclability

All Aluminium & Glass Can Be Recycled

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2017

1

IFC
-

1
