Deko Doors - Aluminium Door - AG

Verified by manufacturer 1 month ago

Deko Doors Double - Aluminium Door - AG

Indeglås Variant:

The Deko Aluminium frame system is based on an aluminium profile which has high stability and ensures a seamless finish.

Jump to:
BOS
+44 (0)1236 453000 Website

Application

DEKO have developed an aluminium snap-on architrave profile. This is clipped onto the frame, providing an attractive joint detail with no visible fixings.

Alternatively, a DEKO Door can be finished with conventional timber architraves or joint filler can be used between the partition and door frame.

Description

The Deko Aluminium frame system is based on an aluminium profile which has high stability and ensures a seamless finish.


Features and benefits:

  • Deko aluminium framed, single glazed, single door system offers a high performance doorset with high stability and acoustic performance up to 42dB whilst maximising light transfer.
  • A variety of glass specifications are available to ensure the product meets client requirements.
  • To compliment this product a series of Fire Doors are also available ensuring uniformity of door design throughout the building.
  • With a variety of width and height options available this product is suitable for fitting to all wall types and is fully compatible with all Deko product ranges.
  • The slim aluminium door frame is unique to this product range and is produced in natural anodised aluminium as standard with the full RAL colour range also available.
  • A range of ironmongery options are available including our standard range of lever and pull handles, latches, locks and closers etc.
  • These can be factory or retro-fitted. The door system is fully compatible with electronic access systems.
  • The Deko distributor will issue production drawings for sign off prior to manufacture to ensure accuracy and the best solution for the project.

General information

Color

Grey

Guidance for specification option:

Natural anodized aluminium.

Other

Guidance for specification option:

Full RAL colour range also available.

Finish

Glazed

Anodized

Material

Glass

Aluminium

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_30_59_23_32 Frameless glass door leavesPrimary

CAWS

L20/460 Frameless glass doors

Specification data - Frameless glass door leaves

Format

Double leaf, single action.

Leaf

-

Colour

Grey.

Guidance for specification option:

Natural anodized aluminium.

RAL.

Guidance for specification option:

full RAL colour range also available.

Hardware

-

Lock

-

Position

Centrally in opening edge of door.

Sound insulation

28—35 dB.

Guidance for specification option:

(NOT TESTED) with and w/o threshold.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Recyclability

All Aluminium & Glass Can Be Recycled

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2017

1

IFC
-

1
