Degafloor Free Flow System - Resin Flooring

Verified by manufacturer 1 month ago

Degafloor Ltd Third party certifications:
  • BREEAM - Certification

    Certificate type

  • European Technical Approval (ETA)

    European Technical Approval (ETA)

    Certificate type

  • UK Conformity Assessed (UKCA)

    UK Conformity Assessed (UKCA)

    Certificate type

  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

A self-levelling flow applied resin system.

Jump to:
BOS
+44 (0)1778 342545 Website

Application

Suitable for the most demanding of areas, such as chemical and pharmaceutical production.

Description

A self-levelling flow applied system.


Combines methyl methacrylate (MMA) resin and fine aggregate. The system is pigmented to create a solid and stable colour with a smooth finish.


Available in a wide variety of colours and specification for installations where colour differentiation and demarcation between areas are important, such as manufacturing, distribution and warehouse areas.


Features and benefits:

  • Durable, fully encapsulated system.
  • Installation - fully cured within two hours at temperatures as low as -20°C.
  • Bonds to existing subfloors.
  • Seamless and impermeable surface without pinholes or air bubbles.
  • Tailored decorative slip resistant finishes.
  • Resistant to UV light, weathering and temperatures up to 80°C.
  • Manufactured in accordance with BS EN ISO 9001:2015 Certificate 20/Q064 Quality Management Systems.

General information

Color

Finish

Smooth

Material

Methyl methacrylate

Guidance for specification option:

Methyl methacrylate resin.

Shape

Formless

Warranty description

Ten year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/110 Resin flooring

M12/10 Resin flooring

Specification data - Resin flooring systems

System performance

Watertight and impervious to moisture.

Substrate

-

Testing

Bond, moisture and compressive tests undertaken by the Degafloor Approved Installer.

Guidance for specification option:

For the Warranty process, prior to installation.

Preparation

Undertake mechanical floor preparation prior to application of primer.

Manufacturer guidance

Dependant on substrate, ie metal, concrete, timber, asphalt.

Primer

-

Manufacturer guidance

Dependant on the substrate, i.e. cementitious, metal, timber, asphalt, tiles. Consult manufacturer and insert requirements.

Resin skirtings and upstands

To match flooring system and colour.

Abrasion resistance

Weight loss <3000 mg.

Adhesion strength

≥2.0 N/mm².

Bond strength

≥B2.0

Capillary absorption

W <0.1 kg/(m²·h^0.5).

Guidance for specification option:

Capillary absorption and permeability to water.

Carbon dioxide permeability

SD >50 m.

Chemical resistance

Reduction in hardness <50%.

Colour

Agate Grey.

Beige.

Blue Grey.

Chocolate Brown.

Fast Blue.

Show more

Curing time

Two hours.

Finish

Smooth.

Impact resistance

Class I, ≥IR 4.

Material

MMA.

Guidance for specification option:

Methyl methacrylate resin.

Reaction to fire

Not tested.

Release of corrosive substances

SR.

Standard

To BS EN 1504 and BS EN 13813.

Third-party certification

To British Board of Agrément-certified (20/Q064).

Water vapour permeability

Class III.

Wear resistance

≤AR 0.5

Cleaning options

Guidance for specification option:

Cleaning equipment and products for all industrial and commercial floor maintenance. Consult manufacturer and insert requirements or omit:

  • Heavy Duty Wet Vacuum 30 Litre.
  • Heavy Duty Wet Vacuum 60 Litre.
  • Degafloor Eco-Clean.
  • The DegaWash Range.
  • Swift95.
  • The Maxey.
  • Emex.
  • Crusader.


Manufacturer guidance

Floor Cleaning Solutions.


See manufacturer literature 'DegaClean Cleaning & Maintenance Brochure'.

Sustainability data

Contains Red List materials

No

Country of material origin

Germany

Country of product manufacture

Germany

Material

Methyl methacrylate

Guidance for specification option:

Methyl methacrylate resin.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit
-

2

Third party certifications

BREEAM - Certification

BREEAM - Certification

FERFA BREEAM Statement

European Technical Approval (ETA)

European Technical Approval (ETA)

Certificate of Conformance for coating of floors in companies where foodstuffs are treated and processed

UK Conformity Assessed (UKCA)

UK Conformity Assessed (UKCA)

UK Certificate of Conformity of the Factory Production Control - UK 0836 CPR 22/F6564

BBA Agrément Certificate

BBA Agrément Certificate

BBA ISO 9001 Certificate

Literature

BS EN ISO 9001 : 2015 Quality Management System

BS EN ISO 9001 : 2015 Quality Management System

Degafloor Free Flow System

Degafloor Free Flow System

DegaClean Cleaning & Maintenance Brochure

DegaClean Cleaning & Maintenance Brochure
