Deckshield Linemarker QD
Verified by manufacturer over a year ago
A single component, solvent based, high build linemarking product.
Application
For use in car parks and segregation areas.
IMPORTANT: All specification information must be checked against the individual site requirements. Flowcrete advises that specifications are confirmed with their technical experts.
Description
A single component, solvent-based, high build linemarking product for use in car parks and segregation areas with adhesion to a wide range of substrates e.g. wood, steel, concrete and Deckshield car park decking systems.
Corporate colours can be produced to special order, consult Flowcrete Technical Department.
Features and benefits:
- Fast drying.
- Easy to apply.
- Abrasion resistant.
General information
Color | White Yellow |
Finish | Gloss |
Material | Other Guidance for specification option: Paint |
Uniclass | |
CAWS | M60/18 Special coating M60/180 Floor coating M60/195 Special coating |
Specification data - Line marking paints
Purpose | Car parks and segregation areas. |
Colour | Yellow.White.Guidance for specification option: Corporate colours can be produced to special order, consult Flowcrete Technical Department. |
Bond strength | Greater than cohesive strength of 25 N/mm² concrete. |
Chemical resistance | Petrol, diesel and oil. |
Cure time | Dry to no pickup: 10 mins, Dry through time: <20 mins, Overcoating: >4 hours. |
Slip resistance | Dry: 90, Wet: 40 TRRL pendulum slip test. |
Temperature resistance | Tolerant up to 80°C. |
Thickness range | 110 microns. Guidance for specification option: (250 microns wet). |
Water permeability | Nil. Guidance for specification option: Karsten test (impermeable). |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 2 |
 Revit | - | 3 |
Literature
Deckshield Car Park Decking
