Data Centre Ultima+ - Mineral Tile Suspended Ceiling System

Verified by manufacturer over a year ago

Board edge infills

Zentia Variant:

Suspended ceiling system with lay-in mineral ceiling tiles.

Jump to:
+44 (0)191 497 1000 Website

Application

Suspended ceiling system, particularly well suited for use in meeting rooms, waiting areas, libraries, language rooms and data centres.

Description

Suspended ceiling system with lay-in mineral ceiling tiles.

Tiles with a finely textured and durable surface with a brighter ‘blue-white’ colour and high light reflectance which offers high levels of sound absorption and sound attenuation.


Features and benefits:

Tiles:

  • Balanced acoustic sound absorption of up to 0.75 αw and sound attenuation of 40 dB.
  • Bright 'blue-white' colour with a high light reflectance (87%).
  • Reinforced scratch-resistant surface.
  • Hard edge treatment.
  • Range of sizes including planks and wide range of different edge details.
  • Low volatile organic compound (VOC) emissions, A+ rating (except Vector: A rating).
  • 100% recyclable.
  • Manufactured using 41% (maximum) recycled material.
  • Cradle to Cradle® certified Bronze.
  • 30-year system guarantee.

General information

Color

White

Finish

Textured

Guidance for specification option:

Infill units only.

Material

Mineral fibre

Steel

Shape

Rectangle

Square

Other

Length

Bespoke

Width

Bespoke

Warranty description

30 year

Guidance for specification option:

System guarantee.

Uniclass

Ss_30_25_22_51 Modular suspended ceiling systemsPrimary

CAWS

K40/10 Unit/ modular suspended ceilings

K40/105 Suspended ceiling system

K40/115 Unit/ modular suspended ceiling system

Product range

Mineral tiles and planks

Specification data - Modular suspended ceiling systems

System performance

Guidance for specification option:

Insert requirements.

Ceiling support

Prelude 24 XL² / TLS, Global White.

Prelude 24 XL² / TLS, White RAL 9010.

Prelude 24 XL² / TLS, Silver RAL 9006.

Prelude 24 XL² / TLS, Black.

Prelude 24 Sixty², Global White.

XL²/ TLS.

Guidance for specification option:

Consult manufacturer for details and insert requirements.

Support fasteners

Guidance for specification option:

Insert requirements to suit substrate.

Ceiling units

600 x 600 x 19 mm board edge mineral tiles in Global White (7661M).

1200 x 600 x 19 mm board edge mineral tiles in Global White (7663M).

Manufacturer guidance

Tiles have a flat, square edges that fully expose a standard suspended ceiling grid.

Recycled content: 41%.

Barriers in ceiling void

-

Fire barriers

Guidance for specification option:

Consult manufacturer for options and insert requirements or omit.

Acoustic barriers

Guidance for specification option:

Consult manufacturer for options and insert requirements or omit.

Plenum barriers

Guidance for specification option:

Consult manufacturer for options and insert requirements or omit.

System accessories

Guidance for specification option:

Consult manufacturer for options and insert requirements or omit.

Weight

Infill units: 5.0 kg/m².

ThermalConductivity

Infill units: 0.052 W/m·K.

Reaction to fire

To EN 13501-1, infill units: Euroclass A2-s1, d0; support grid: Euroclass A1.

RelativeHumidity

Infill units: 95%.

Formaldehyde emissions

Infill units: To EN 13964, E1.

Cleanroom classification

To ISO 14644-1, ISO 5.

Sound absorption

Infill units: αw = 0.70 (H); Class C.

Guidance for specification option:

Board, Tegular, MicroLook 90 and Finesse:


Weighted sound absorption coefficient (alpha w). Rating for random incidence sound absorption determined in accordance with BS EN ISO 11654. Measured values obtained in accordance with BS EN ISO 20354 are converted into octave bands, plotted on a graph and compared to a standard reference curve until a 'best fit' is obtained. The derived αw will vary between 0.00 and 1.00.

Noise reduction coefficient

To EN ISO 140-3 & EN ISO 717-1, 0.75.

Colour (Light reflectance value (LRV)

Infill units: 87%.

Weighted sound reduction index, Rw

To EN ISO 140-3 & EN ISO 717-1, 18 dB.

Sound attenuation

Infill units: Acoustic attenuation to EN ISO 354 & EN ISO 11654, Dnfw = 36 dB.

Manufacturer guidance

Infill units only.

Dnfw rating derived from laboratory measurement of room-to-room airborne sound insulation of suspended ceiling with plenum above. Rating determined in accordance with EN ISO 717-1 from measurements made in accordance with EN IS0 10848-2 over the third-octave band frequency range 100–3150 Hz.

Sustainability data

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

41 %

Guidance for specification option:

Infill units only; consult manufacturer for details of supporting grid.
