DaneFlash® - Roof Flashing
Verified by manufacturer 16 hours ago
DANEFLASH 140
DANEFLASH 140
DaneFlash is a lead-free flexible roof flashing that can be used in a range of applications due to the self-vulcanising outer surface and fully self-adhesive backing.
Application
Suitable for roofs where a flashing solution is required, including:
- Roof junctions.
- Roof penetrations.
- Roof windows and rooflights.
- PV systems.
- Rigid metal and GRP flashing junctions.
- Saddles and soakers.
Description
DaneFlash® is a fully recyclable, lead-free flexible flashing material with self-adhesive backing, used on roofs and other building surfaces.
Features and benefits:
- Universal application.
- Lead replacement.
- Over 50% faster to install than lead.
- Uncontaminated water run-off suitable for harvesting.
- Lightweight.
- No scrap value.
- Fully adhesive backing.
- Self-vulcanizing outer surface.
- Usable off-cuts to minimize waste.
- PFAS free and 100% recyclable.
General information
Color | Black Grey Red |
Finish | Smooth |
Material | Polyisobutylene (PIB) |
Shape | Rectangle |
Length | 5000 mm |
Width | 140 mm 280 mm 370 mm 560 mm |
Height | 2.2 mm |
Warranty description | 20 year |
Uniclass | |
CAWS | H67/85 Vertical metal tiling – internal corner with flashing H31/80 Flashing/ trims H62/3 Roof slating H65/5 Roof tiling H62/105 Roof slating |
SKU Code | DANEFLASH 140 |
Specification data - Butyl rubber adhesive tapes
Classification data | |
Bond | Single-sided. |
Core | Butyl rubber. |
Size | 2.2 x 140 mm wide. Guidance for specification option: Thickness tolerance: +/-0.2 mm. Manufacturer guidanceLength x width x thickness. |
Colour | Slate grey. Black. Tile red. Guidance for specification option: Available upon request. |
Roll length | 5 m. |
Weight | 4.7 kg/m². |
Installation temperature | -10 to +60°C. |
Service temperature range | -60 to +80°C. |
Sustainability data
Contains Red List materials | No |
Material | Polyisobutylene (PIB) |
Recyclability | 100% recyclable Guidance for specification option: For recycling at the end of service life, product should be sent to specific facility, contact Hambleside Danelaw for further information. |
Expected Life | 20 year |
