D230W Double Non-Return Valve

Name: D230W Double Non-Return Valve
Brand: Crane Fluid Systems
SKU: ueDPKGLdB3vqzJD9jeR3b2

Verified by manufacturer 26 days ago

DN50

A cast iron, double non-return valve.

Jump to:

Application

Suitable for pipelines generally.

A cast iron, double non-return valve.

Features and benefits:

Color	Black
Material	Cast iron

Uniclass	Pr_65_54_30_12 Gas fire-suppression check valvesPrimary

Standard	To BS EN 1092-2 and BS EN 3692.
Third party certification	The Water Regulations Advisory Scheme (WRAS). Guidance for specification option: These valves are not intended to be used as backflow prevention devices conforming to Schedule 2 Section 6 of the WRAS Water Regulations Guide. Two suitably approved single check valves (Type EA device) installed in series are accepted as offering the equivalent level of protection as that afforded by a double check valve (Type EC device) providing the maximum distance between the adjacent flanges of the valves did not exceed twice their nominal bore and the operation of one component does not interfere with the operation of the other.
Valve type	Non-return valve.
Material	Cast iron 1 EN-GJL-250, Steel (zinc plated) Grade 8.8 / 8, Stainless steel 316/304, Fusion bonded epoxy cast iron 1561 EN-GJL-250, EPDM, Stainless steel 304 (1.4301) and Brass 12164 CW611N. Guidance for specification option: Body, Guide: Cast iron; Disc: Fusion bonded epoxy cast iron; Seat, Gasket: EPDM; Spring, Stem, Plug 1/4": Stainless steel; Bushing: Brass; Stud, Nut: Steel.
Working pressure	16 BAR.
Cross-sectional area	Manufacturer's standard.

Inlets/outlets diameter	50 mm.
Dimensions	203 x 165 mm.
Weight	17 kg.
Operating temperature range	-10 to 120°C. Manufacturer guidance WRAS approved to 85°C.
Connection	Flanged.
