D191 Ball Valve

Name: D191 Ball Valve
Brand: Crane Fluid Systems
SKU: p8pobAD3pLmpTyKcmrm5oB

Verified by manufacturer 1 month ago

DN8

A threaded DZR ball valve.

Jump to:

Application

Suitable for use in plumbing pipework and natural gas applications.

A threaded DZR ball valve.

Features and benefits:

Designed to be light, compact and easy to install and operate.
Features improved leak resistance and reduced risk of damage from over tightening.
Tested by BSI and complies with essential requirements of BS EN 331:1998.
Also suitable for natural gas applications.

Color	Yellow Guidance for specification option: Handle sleeve
Material	Brass Guidance for specification option: DZR brass

Uniclass	Pr_65_54_95_06 Ball valvesPrimary Pr_65_54_33_33 Gas ball valves
CAWS	S90/625 Ball valves S90/625 Ball valves S91/350 Gas ball valves S91/350 Gas ball valves

Material	DZR Brass; Steel; PVC; EPDM; Aluminium, NBR and PTFE. Guidance for specification option: Hex-Nut, Handle: Dacromet plated steel; Handle sleeve: PVC yellow. Packing nut, Body, Ball, Stem: Brass; Packing gland, Seats: PTFE; O-Ring: NBR.
Connections	Taper threaded to BS EN 10226-2 (ISO 7-1). ANSI B1.20.1:1983. Guidance for specification option: Please add suffix AT to denote American Thread.
Finish	Hex-Nut (dacromet plated steel); Handle (dacromet plated steel ); Handle sleeve (yellow PVC); Ball (DZR brass chrome plated).

Standards	To BS EN 10226-2 (ISO 7-1); BS EN 331:1998; BS EN 549.
Third-party certification	WRAS approved.
Inlets/outlets diameter	DN8.
Dimensions	46 x 41 mm. Manufacturer guidance Refer to technical datasheet for detailed dimensions.
Weight	0.152 kg.
Operator	Lever. Guidance for specification option: Quarter turn.
PressureRange	Temperature: -10 to +100°C: 25 bar, Temperature: +110°C: 23.5 bar, Temperature (natural gas): -20 to +60°C: 5 bar.

Material	Brass Guidance for specification option: DZR brass
Recyclability	Recyclable Guidance for specification option: Recycle locally, consult manufacturer for details.
Expected Life	20 year
