Creation 55 Rigid Acoustic (Mineral) - Commercial flooring

Verified by manufacturer 2 months ago

0868 - Bloom Uni Taupe

Gerflor Flooring UK Limited Variant:

Synthetic, decorative, rigid, anti-static mineral effect floor coverings with integrated acoustic underlay available in tile or plank form with interlocking system for quick and easy installation.

Jump to:
BOS
01625 428 922 Website

Application

Suitable for commercial applications.

Description

Creation 55 Rigid Acoustic is a decorative and acoustic range of luxury vinyl tiles (LVT) and planks with full rigid board technology.


It comprises a 0.55 mm transparent crystal wear layer, 4D design film and rigid core technology for stability and easy renovation. The rigid core technology and integrated acoustic underlay deliver 19 dB of impact sound insulation. Creation 55 Rigid Acoustic includes an enhanced surface treatment, Protecshield™, for improved scratch and stain resistance, easy cleaning and an ultra matt finish.


It is available in various sizes, including wood and mineral design references, offering a good range of design choice.


Features and benefits:

  • Full rigid board technology.
  • Four bevelled edges for tiles and planks effect.
  • Durable construction – suitable for medium traffic commercial applications.
  • Wear Group T/ Type Binder classification I.
  • Protecshield™ surface treatment for easy cleaning and maintenance.
  • Slip resistant - R10.
  • Enhanced acoustic properties through integrated underlay – 19 dB impact sound insulation.
  • Easy and quick to install using standard interlocking technology.
  • Good range of designs.
  • 100% recyclable.
  • All references also available as standard Creation 55 Looselay (non-acoustic version) – specified separately.
  • Other products in the Creation 55 range include: Creation 55, Creation 55 Clic, Creation 55 Looselay and Creation 55 Looselay Acoustic (specified separately).


Installation and maintenance:

Should be installed in accordance with the BS 8203:2017 code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available.

General information

Color

Other

Guidance for specification option:

Please see specification data for options.

Finish

Matt

Material

Vinyl

Shape

Rectangle

Length

1219 mm

1524 mm

914 mm

750 mm

Width

177 mm

225 mm

457 mm

125 mm

Height

6 mm

Warranty description

12 year

Uniclass

Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Product range

Tiles / Luxury Vinyl Tile (Flooring)

Specification data - Polyvinyl chloride (PVC) tiles

Standard

To BS EN ISO 10582.

Use class

To EN ISO 10874, class 33-42.

Guidance for specification option:

Commercial, very heavy - Light industrial, general.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Guidance for specification option:

To DIN 51130 slip resistance wet.

Recycled content

35%.

Guidance for specification option:

Contains up to 35% recycled content.

Size

177 x 1219 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 8/ 1.73 m².

225 x 1524 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 5/ 1.71 m².

457 x 914 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 4/ 1.67 m².

125 x 750 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 16/ 1.5 m².

Thickness

6.0 mm.

Guidance for specification option:

To EN ISO 24346.

Colour and pattern

Bloom Uni Taupe.

Weight

9480 g/m².

Guidance for specification option:

To EN ISO 23997.

Wear resistance

< 2.0 mm³.

Guidance for specification option:

To EN 660.2.

Wear group

T.

Binder

Type I.

Guidance for specification option:

Type binder content to ISO 10582.

Impact sound reduction (to EN-ISO 717-2)

19 dB.

Dimensional stability (to BS EN ISO 23999)

≤ 0.15%.

Guidance for specification option:

Average measured value ≤ 0.10%.

Residual indentation (to EN-ISO 24343-1)

≤ 0.10 mm.

ThermalConductivity

0.25 W/m·K.

Guidance for specification option:

To EN ISO 10456.

Surface treatment

Protecshield™.

Chemical resistance (to EN-ISO 26987)

OK.

Static electricity

< 2 kV.

Guidance for specification option:

To BS EN 1815, static electricity electrical propensity.

Fire classification (to EN ISO 13501-1)

Bfl-s1.

VOC emissions

< 10 µg/m³.

Guidance for specification option:

To ISO 16000-6, TVOC after 28 days.

Wear layer thickness

0.55 mm.

Guidance for specification option:

To EN ISO 24340.

Accessories

Design skirting.

Design coverstrip.

Entrance matting.

Not required.

Manufacturer guidance

Consult manufacturer's literature and insert requirements.

Colour (Light reflectance value (LRV)

28.5.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Europe

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

35 %

Guidance for specification option:

Contains up to 35% recycled content.
