Creation 55 Rigid Acoustic (Mineral) - Commercial flooring
Verified by manufacturer 3 months ago
0868 - Bloom Uni Taupe
0868 - Bloom Uni Taupe
Synthetic, decorative, rigid, anti-static mineral effect floor coverings with integrated acoustic underlay available in tile or plank form with interlocking system for quick and easy installation.
Application
Suitable for commercial applications.
Description
Creation 55 Rigid Acoustic is a decorative and acoustic range of luxury vinyl tiles (LVT) and planks with full rigid board technology.
It comprises a 0.55 mm transparent crystal wear layer, 4D design film and rigid core technology for stability and easy renovation. The rigid core technology and integrated acoustic underlay deliver 19 dB of impact sound insulation. Creation 55 Rigid Acoustic includes an enhanced surface treatment, Protecshield™, for improved scratch and stain resistance, easy cleaning and an ultra matt finish.
It is available in various sizes, including wood and mineral design references, offering a good range of design choice.
Features and benefits:
- Full rigid board technology.
- Four bevelled edges for tiles and planks effect.
- Durable construction – suitable for medium traffic commercial applications.
- Wear Group T/ Type Binder classification I.
- Protecshield™ surface treatment for easy cleaning and maintenance.
- Slip resistant - R10.
- Enhanced acoustic properties through integrated underlay – 19 dB impact sound insulation.
- Easy and quick to install using standard interlocking technology.
- Good range of designs.
- 100% recyclable.
- All references also available as standard Creation 55 Looselay (non-acoustic version) – specified separately.
- Other products in the Creation 55 range include: Creation 55, Creation 55 Clic, Creation 55 Looselay and Creation 55 Looselay Acoustic (specified separately).
Installation and maintenance:
Should be installed in accordance with the BS 8203:2017 code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available.
General information
Color | Other Guidance for specification option: Please see specification data for options. |
Finish | Matt |
Material | Vinyl |
Shape | Rectangle |
Length | 1219 mm 1524 mm 914 mm 750 mm |
Width | 177 mm 225 mm 457 mm 125 mm |
Height | 6 mm |
Warranty description | 12 year |
Uniclass | |
CAWS | M50/10 Resilient floor tiling M50/110 Resilient floor tiling |
Product range |
Specification data - Polyvinyl chloride (PVC) tiles
Standard | To BS EN ISO 10582. |
Use class | To EN ISO 10874, class 33-42.Guidance for specification option: Commercial, very heavy - Light industrial, general. |
Slip potential | |
Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum) | R10.Guidance for specification option: To DIN 51130 slip resistance wet. |
Recycled content | 35%.Guidance for specification option: Contains up to 35% recycled content. |
Size | 177 x 1219 mm.Guidance for specification option: Number of planks/ tiles and sqm per box: 8/ 1.73 m². 225 x 1524 mm.Guidance for specification option: Number of planks/ tiles and sqm per box: 5/ 1.71 m². 457 x 914 mm.Guidance for specification option: Number of planks/ tiles and sqm per box: 4/ 1.67 m². 125 x 750 mm.Guidance for specification option: Number of planks/ tiles and sqm per box: 16/ 1.5 m². |
Thickness | 6.0 mm.Guidance for specification option: To EN ISO 24346. |
Colour and pattern | Bloom Uni Taupe. |
Weight | 9480 g/m². Guidance for specification option: To EN ISO 23997. |
Wear resistance | < 2.0 mm³. Guidance for specification option: To EN 660.2. |
Wear group | T. |
Binder | Type I. Guidance for specification option: Type binder content to ISO 10582. |
Impact sound reduction (to EN-ISO 717-2) | 19 dB. |
Dimensional stability (to BS EN ISO 23999) | ≤ 0.15%. Guidance for specification option: Average measured value ≤ 0.10%. |
Residual indentation (to EN-ISO 24343-1) | ≤ 0.10 mm. |
ThermalConductivity | 0.25 W/m·K. Guidance for specification option: To EN ISO 10456. |
Surface treatment | Protecshield™. |
Chemical resistance (to EN-ISO 26987) | OK. |
Static electricity | < 2 kV. Guidance for specification option: To BS EN 1815, static electricity electrical propensity. |
Fire classification (to EN ISO 13501-1) | Bfl-s1. |
VOC emissions | < 10 µg/m³. Guidance for specification option: To ISO 16000-6, TVOC after 28 days. |
Wear layer thickness | 0.55 mm. Guidance for specification option: To EN ISO 24340. |
Accessories | Design skirting. Design coverstrip. Entrance matting. Not required. Manufacturer guidanceConsult manufacturer's literature and insert requirements. |
Colour (Light reflectance value (LRV) | 28.5. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | Europe |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 35 % Guidance for specification option: Contains up to 35% recycled content. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
Creation 55 - 2022 Collection
Finishing Solutions for LVT Flooring
