Creation 40 Rigid Acoustic - Residential flooring

Verified by manufacturer 8 months ago

0347 - Ballerina

Gerflor Flooring UK Limited Variant:

Synthetic, decorative, rigid, anti-static floor coverings with integrated acoustic underlay available in tile or plank form with interlocking system for quick and easy installation.

Jump to:
BOS
01625 428 922 Website

Application

Suitable for residential applications.

Description

Creation 40 Rigid Acoustic is a decorative and acoustic range of luxury vinyl tiles (LVT) and planks with a 0.40 mm transparent wear layer.


It comprises a RCB (rigid composite board) patented technology and an integrated acoustic layer. The rigid core technology and integrated acoustic underlay delivers 19 dB of impact sound insulation. Creation 40 Rigid Acoustic is finished with an enhanced surface treatment, Protecshield™, for improved scratch and stain resistance, easy cleaning and an ultra matt finish.


It is available in three sizes and 30 core designs that includes wood and mineral design references, offering a good range of design choice.


Features and benefits:


  • RCB (rigid composite board) patented technology: easy to carry.
  • High definition of design and structured emboss.
  • Four bevelled edges for tiles and planks effect.
  • Protecshield™ surface treatment for easy cleaning and maintenance and enhanced scratch and stain resistance.
  • Wear Group T/ Type Binder classification I.
  • Slip resistant - R10.
  • Enhanced acoustic properties – 19 dB impact sound insulation.
  • Easy and quick to install using standard interlocking technology.
  • Good range of designs.
  • 100% recyclable and contains up to 35% recycled content.


Installation and maintenance:

Should be installed in accordance with the BS 8203:2017 code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available.

General information

Color

Beige

Black

Brown

Cream

Grey

Finish

Matt

Material

Vinyl

Shape

Rectangle

Length

1250 mm

1492 mm

730 mm

Width

229 mm

399 mm

Height

5.7 mm

Guidance for specification option:

Total thickness to EN ISO 24346.

Warranty description

12 year

Uniclass

Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Product range

Tiles / Luxury Vinyl Tile (Flooring)

Specification data - Polyvinyl chloride (PVC) tiles

Standard

To BS EN ISO 10582

Use class

To BS EN 10874, class 23-32-41.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Guidance for specification option:

To DIN 51130 slip resistance wet.

Recycled content

35%.

Guidance for specification option:

Contains up to 35% recycled content.

Size

229 x 1250 mm.

Guidance for specification option:

Number of planks and sqm per box: 7/ 2.0 m².

399 x 730 mm.

Guidance for specification option:

Number of planks and sqm per box: 7/ 2.04 m².

229 x 1492 mm.

Guidance for specification option:

Number of planks and sqm per box: 7/ 2.39 m².

Manufacturer guidance

To EN ISO 24342.

Thickness

5.7 mm.

Guidance for specification option:

To EN ISO 24346.

Colour and pattern

0347 Ballerina.

Weight

7000 g/m².

Guidance for specification option:

To EN ISO 23997.

Wear layer

0.40 mm.

Guidance for specification option:

Wear layer thickness to EN ISO 24340.

Wear resistance

< 2.0 mm³.

Guidance for specification option:

To EN 660.2.

Wear group

T.

Binder

Type I.

Guidance for specification option:

Type binder content to ISO 10582.

Impact sound reduction (to EN-ISO 717-2)

19 dB.

Dimensional stability (to BS EN ISO 23999)

≤ 0.15%.

Guidance for specification option:

Average measured value, ≤0.10%.

Residual indentation (to EN-ISO 24343-1)

≤ 0.10 mm.

ThermalConductivity

0.25 W/m·K.

Guidance for specification option:

To EN ISO 10456.

Surface treatment

Protecshield™.

Chemical resistance (to EN-ISO 26987)

OK.

Static electricity

< 2 kV.

Guidance for specification option:

To BS EN 1815, static electricity electrical propensity.

Fire classification (EN 13501-1)

Bfl-s1.

VOC emissions

< 10 µg/m³.

Guidance for specification option:

To ISO 16000-6 TVOC after 28 days.

Light reflectance value (LRV)/ Colour

28.4.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Europe

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

35 %

Guidance for specification option:

Contains up to 35% recycled content.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Creation 40 - 2022 Collection - Card

Creation 40 - 2022 Collection - Card
