CoresoundB Acoustic Flooring System (AFS)

Name: CoresoundB Acoustic Flooring System (AFS)
Brand: CMS Danskin Acoustics
SKU: pGCbZgj37CjEBMGY9nm4yx

Verified by manufacturer 3 days ago

CoresoundB AFS30

Acoustic flooring system combining Gyvlon® screeds and REGUPOL sonus core underscreeds to develop a thin cross-section, low-weight floor levelling system that reduces impact noise transmission.

Jump to:

Request BIM

+44 (0)1925 577711 Website

Application

Suitable for flooring applications and particularly suitable for projects that need to maximum space e.g. renovation projects with limited ceiling heights.

Description

Acoustic flooring system combining the experience of Gyvlon® screeds and REGUPOL sonus core underscreeds to develop a thin cross-section, low-weight floor levelling system that reduces impact noise transmission.

Features and benefits:

Choice of three different total build up heights: 30, 35 and 40 mm.
Reduced noise levels from sound travelling through the floor help create a quieter, more comforable living and working environment.
The CoresoundB is thinner and lighter when compared to traditional systems.
ΔLw up to 22 dB depending on the build up specified.

General information

Color	Black Grey
Material	Rubber
Shape	Rectangle Formless
Length	Bespoke
Width	Bespoke
Height	Bespoke

Uniclass	Ss_30_42_72_72 Resilient sheet floor covering systemsPrimary
CAWS	M10/40 Floating construction M10/295 Floating construction (thin sheet impact sound insulation) M10/195 Proprietary screeds to BS EN 13813

Specification data - Resilient sheet floor covering systems

Classification data
Smoothing and levelling underlayment compound	Gryvlon FINIO® 25 mm screed.
Resilient underlayer	-
Type	REGUPOL sonus core 5, acoustic underscreed.
Sheet	-
Type	Manufacturer's standard separating membrane.
System accessories	Perimeter isolating/ expansion strips.
Acoustic performance	ΔLw: 20 dB.
Overall thickness	30 mm.
