Conex Bänninger Gate Valves
Application

Closed circuit heating and cooling services, waste, oil-free compressed air, vacuum, rainwater.

Description

Brass gate valves.

Features and benefits:

  • Non-rising stem.
  • High quality brass construction.
  • WRAS approved for drinking water.
  • Suitable for low temperature hot water systems.
  • Not suitable for high temperature working, temperatures above 100°C.
  • Designed in accordance with EN 12288 requirements, end connections, female taper threads to EN 10226-2 (ISO 7-1).

Application:

Closed circuit heating and cooling services, waste, oil-free compressed air, vacuum, rainwater.

General information

Size

Features

Non-rising stem, high quality brass construction, WRAS approved for drinking water, suitable for low temperature hot water systems, not suitable for high temperature working, temperatures above 100°C, designed in accordance with EN 12288 requirements, end connections, female taper threads to EN 10226-2 (ISO 7-1)

Material

Brass

WarrantyDescription

5 years the date of first purchase

Uniclass 2015

Pr_65_54_95_15 Copper alloy gate valvesPrimary

CAWS

S90/10 Mains cold water supply

S90/11 Storage cold water supply

S90/110 Mains cold water supply

S90/12 Instantaneous hot water supply

S90/120 Storage cold water supply

Show more
Specification data - Copper alloy gate valves

Product Reference

Conex Bänninger Gate Valves

1120 Gate Valve 1/2" to 2"

Conex Bänninger Gate Valves

1121 Gate Valve 1/2" to 2"

Conex Bänninger Gate Valves

1122 Gate Valve 1/2" to 2"

Conex Bänninger Gate Valves

1124 Gate Valve 1/2" to 2"

Conex Bänninger Gate Valves

.1126 Gate Valve 1/2" to 2"

Standard

EN 10226-2 (ISO 7-1), EN 12288, EN 12164 CW617N-DW, EN 12164 CW614N, EN 12165 CW617N-DW, EN 12164 CW602N, EN 12164 CW614N, EN 1706 LM6, EN 12164 CW614N, EN 1706 LM6

Series

Bänninger gate valves

TemperatureRange

-10 to +110°C

Pressure

-

Bar

20

Psi

290

Valve suitability

Water, drinking water, oil

Size

Insert requirement.

Standard product features

Features:

Non-rising stem, high quality brass construction, WRAS approved for drinking water, suitable for low temperature hot water systems, not suitable for high temperature working, temperatures above 100°C, designed in accordance with EN 12288 requirements, end connections, female taper threads to EN 10226-2 (ISO 7-1).

Material:

Brass.

Size:

Many options available.

Warranty description:

5 years the date of first purchase.

Recyclability:

Recyclable.

Country of origin:

China

Environmental information

Recyclability

Recyclable

Third party certifications
  • WRAS
