Condair DP-W - Wall Mounted Swimming Pool Dehumidifiers
Compare variants

Condair DP-W - Wall Mounted Swimming Pool Dehumidifiers

DP 50-W

Condair Limited Variant:

Dehumidification for swimming pools, spas and therapeutic clinics.

Jump to:
+44 (0)1903 850200 www.condair.co.uk

Application

  • Dehumidification for swimming pools, spas and therapeutic clinics.
  • Condair DP-W suitable for use in smaller private swimming pools up to medium-sized indoor pools.
  • Condair DP-R suitable for concealed applications.

Description

Range of dehumidifiers for swimming pools, spas and therapeutic clinics.



Features and benefits:

  • Secure, dry running surfaces.
  • A comfortable, ambient atmosphere instead of an unpleasant, sticky heat sensation.
  • Prevents mold, rust or damage to the building.
  • Available in a variety of performance categories and comfort levels.
  • Cooling circuit technology, in which the refrigerant is compressed and released on a throttle, with the advantage of economy, when compared to conventional systems utilizing input air (up to 60% more economic).
  • Integrated heat recovery unit is based on the principle of the heat pump, resulting in notable savings in energy expenditure, as the heat is recovered within the heat pump circuit and fed to the air in the indoor pool through the dry inlet air.


Condair DP-W (Wall-mounted):

  • Relatively low construction depth of between 260 and 310 mm makes it easy to install and retrofit.
  • For use in smaller private swimming pools up to medium-sized indoor pools.
  • Available in five different performance capacities, with a maximum dehumidification capacity of 49 to 190 L/day.
  • Stand-alone solution with quiet operation.
  • Can be extended to include a hot water or electric heater coil, electronic or mechanical humidity switches, supporting feet, and further accessories.
  • User-friendly control interface.


Condair DP-R (Installation behind partition):

  • Suitable for concealed applications.
  • Developed as rear wall units accommodated on the wall of a neighbouring room, or in a separate utility room.
  • Rear wall unit design eliminates all operating noises caused by sound-emitting components from the guest area, such as compressors or fans.
  • Space saving with no adverse effect upon the pool’s spatial and conceptual design.
  • Available in five different sizes and a maximum dehumidifying capacity of 49 to 190 L/day.
  • Can be connected to the inside of the pool area via two wall openings using Condair’s optional ventilation duct, which reduces space requirements inside the pool area, with only the input and output air grille visible.
  • Can be extended to include a hot water or electric heater coil, electronic or mechanical humidity switches, supporting feet, and further accessories.

General information

Color

Silver

White

Shape

Rectangle

Housing.

Size

H x W x D.

750 x 835 x 260 mm

DR 50-W.

750 x 1135 x 260 mm

DP 75-W, DP 100-W.

840 x 1384 x 310 mm

DP 150-W, DP 200-W.

680 x 706 x 250 mm

DP 50-R.

680 x 1006 x 250 mm

DP 75-R, DP 100-R.

Show more

Uniclass

Pr_65_67_39_22 Desiccant dehumidifiersPrimary

Specification data - Desiccant dehumidifiers Enhanced data

Arrangement

In-room, wall-mounted, dehumidification unit.

Mounted in space being dehumidified.

Behind partition, wall-mounted, ducting, dehumidification unit.

Mounting adjacent to space being dehumidified, with ducting to and from the room being humidified.

Duty

-

Air volume

500 m³/h.

Electrical supply type

Single phase.

Accessories:

Additional accessories available, consult manufacturer for details.

Not required.

Hot water coil.

Electric heater coil.

Electronic humidity switches.

Mechanical humidity switches.

Show more

Performance

Dehumidification capacity.

49 L/24h.

At 30°C, 80% RH.

39 L/24h.

At 30°C, 60% RH.

35.9 L/24h.

At 28°C, 60% RH.

33.4 L/24h.

At 26°C, 60% RH.

Current

Maximum current consumption (full load current).

3.9 A.

TemperatureRange

Temperature, humidity operating range.

Temperature: 20–36°C, Humidity: 50–99% RH.

Voltage supply

230 V, Single phase, 50 Hz.

Dimensions

H x W x D.

750 x 835 x 260 mm.

SoundPressure

Laboratory values in 1 m free field according to ISO 9614, actual values may differ.

47 dB(A).

Weight

50 kg.

Pressure

Compression available, with higher compression optional.

40 Pa.

NominalPowerConsumption

At tR = 30°C, humidity = 80% RH.

0.9 kW.

InternalRefrigerantVolume

Refrigerant type R410A.

470 g.

Global warming potential (GWP)

R410A global warming potential (GWP) = 2,088 CO2e.

CO2Content

Total of CO2 equivalent.

0.98 t-CO2 e.

Maximum power usage

At tR = 35°C, humidity = 75% RH.

1.2 kW.

Without electrical heater coil.

Heater

PWW heater, at tR = 30°C; water temperature 80/ 70°C, compressor in standby.

3.5 kW.

Power output

Electrical heater.

Not required.

3 kW.
