Concrete + Composed LVT Collection: Composed 098UV

Name: Concrete + Composed LVT Collection: Composed 098UV
Brand: Shaw Contract
SKU: tgqddfj6a3rkus2PYtmAub

Verified by manufacturer 5 months ago

00103

Shaw Contract

Rigid Core LVT floor covering.

Jump to:

BOS

+44 (0)20 79614120 Website

Application

Suitable for heavy commercial use.

Recommended installation methods:

Brick; Ashlar; Stagger.

Description

Rigid Core LVT. The dimensionally stable construction and high-density core is ideal for high traffic commercial environments with low maintenance and quick installation. Rich wood grain visuals and textured concrete provide a foundation of beauty and performance.

Features and benefits:

Multilayer spc with attached cork underlayment.
15-year commercial limited warranty.
CE marked and Environmental product declaration.
ExoGuard™ finish.
FloorScore® certified.
We want it back: At the end of its useful life, we’ll reclaim and recycle or reuse our carpet tiles through our reTURN scheme
Adhesive-Free Installation: IOBAC MagTabs™

General information

Color	Grey
Material	Composite
Shape	Rectangle
Length	182 mm
Width	1220 mm
Height	5.5 mm
Warranty description	15 year

Uniclass	Pr_35_57_71_41 Interlocking laminate floor tilesPrimary
CAWS	M50/10 Resilient floor tiling M50/110 Resilient floor tiling

Product range	Concrete + Composed LV

Specification data - Interlocking laminate floor tiles

Standard	To BS EN 14041.
Use class	To BS EN ISO 10874, class 34.
Slip potential	-
Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)	To BS 7976-2, 46 (dry), 34 (wet).
Surface roughness (Rz) (minimum)	R9.
Size	-
Thickness	55 mm.
Finish	ExoGuard™ quartz enhanced urethane.
Colour and pattern	Orchard.

Mass	To EN ISO 23997, 7.80 kg/m².
Tile size	182 x 1220 mm.
FlammabilityRating	To EN 13501-1, Bfl-S1 (unadhered testing).
Thermal resistance	0.037 m²K/W.
Residual indentation	To EN ISO 24343-1, 0.06 mm.
Sound absorption	To ISO 354, 0.10 αw.
Light reflectance	24.4.
Primary backing	Cork.
Materials	Stone plastic composite.

Sustainability data

Country of material origin	China
Country of product manufacture	United Kingdom
Recyclability	- Manufacturer guidance re[TURN] TakeBack scheme.

BIM objects

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform	Compatible	Version
IFC	-	1
Revit	-	1
