Concept Cube 55 cm short projection washbasin, 2 tap holes with overflow
Verified by manufacturer over a year ago
Short projection washbasin, with two tap holes and overflow.
Application
For use as washbasin.
Description
Concept Cube 55 cm short projection washbasin, two tap holes with overflow.
Features and benefits:
- Domestic and commercial use.
- Wall, pedestal or semi-pedestal washbasin with space saving short projection.
- Part of the extensive Concept suite.
- One and two tap hole options.
- Space saving design.
- Capacity:
General information
Color | White |
Finish | Polished |
Material | Vitreous china |
Width | 550 mm |
Height | 170 mm |
Uniclass | |
CAWS | N13/335 Washbasins N13/30 Washbasins |
Specification data - Pedestal washbasins
Form | Full pedestal.Semi pedestal.Wall mounted. |
Materials | |
Body | Vitreous china to BS 3402. |
Finish and colour | Polished.Manufacturer guidanceWhite. |
Size | 550 x 380 x 170 mm.Guidance for specification option: W x D x H. |
Water supply, overflow and waste holes | |
Water supply | Single tap hole, centred. |
Overflow | Rear overflow hole. |
Waste | Bottom waste outlet. Chainstay hole. |
Weight | 15.09 kg. |
Capacity | 4.1 Litres. |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
