NBS Source
Compact
Compare variants

Compact

Verified by manufacturer 3 months ago

Compact K1

Stelrad Radiators Variant:

Compact radiator available in a range of variations.

Jump to:
0800 876 6813 www.stelrad.com

Application

Suitable for various rooms and applications where space is at a premium.

Description

Compact radiator available in a range of variations.


Features and benefits:

  • Performs to a maximum working pressure of 145 psi (10 bar).
  • Conforms to BS EN 442.
  • Available in a range of over 200 sizes in horizontal and vertical configurations, providing extra sizing flexibility to cover a multitude of application requirements.
  • White (RAL 9016) in colour.
  • The integrated top grille and side panels have been specifically designed to eradicate any movement, providing a tight, professional fit that will remain in place, even after storage, transit, and installation.
  • The convectors are precision welded directly onto the waterways for greater efficiency and economy, with flexible connection options for the highest of commercial and domestic application specifications.
  • Accessories are available to ensure that the Stelrad Compact can be fitted within a wide range of applications - consult manufacturer for details.
  • Sections: Dependent on size and style, consult manufacturer's literature for information.
  • Technical characteristics: Dependent on size and style, consult manufacturer's literature for information.
  • Style: Certain styles are only available with certain sizes, consult manufacturer for information.

General information

Color

White

Finish

Painted

Material

Steel

Shape

Rectangle

WarrantyDescription

Ten year

Horizontal models.

Uniclass

Pr_70_60_36_73 RadiatorsPrimary

CAWS

T90/465 Radiators

T90/465 Radiators

Specification data - Radiators

Standards

To BS EN 442.

Radiator type

Single panel.

Output

255–3351 W (870–11 473 Btu/h).

Dependent on size and columns, consult manufacturer's literature for details.

Finish

Painted.

Connections

½” inlet.

As standard.

Accessories

Not required.

Floor mounting brackets.

Size (h x l)

300–700 x 300–3000 mm.

Available in a range of 184 sizes; heights of 300–700 mm and widths of 300–3000 mm.

Consult manufacturer's literature for details and insert requirements.

Centre tap thermostatic radiator valve (TRV)

Not applicable.

WorkingPressure

10 bar.

Operating pressure (maximum)

13.5 bar.

Configuration

Horizontal.

Depth

61 mm.

Projection

94 mm.
