Comar LS+ - Lift/ Slide Doorset
Verified by manufacturer 15 hours ago
Lift and slide doorset.
Application
Ideal for all applications that would benefit from superior aesthetics and increasing the amount of natural light to transform the space inside and out.
Description
Innovative lift and slide gearing provides smooth operation for doors up to 12 m wide and 3 m high.
From one system Comar 7P.i LS+ provides delivered solutions, for the summer months maximize the opening space with the three-track slider, whilst in the winter the lowest U-values keep out the cold.
Innovation comes from Comar 7P.i LS+ offering unique solutions from one system, which means that with the same profiles you can provide lift slide or straight rolling gear, standard or slim interlock, enhanced performance with the inclusion of thermal foam and double or triple track configurations.
Features and benefits:
- Lift/ Slide Gear.
- Straight rolling option.
- Two or three track options.
- Standard interlock.
- Slim interlock.
- Each door 3000 mm wide.
- Each door up to 3000 mm high.
- Sliding wall up to 12 m.
- Meets the requirements of PAS 24: 2022 and BS 6375-1, -2 and -3.
- Kitemarked.
- Secured by Design.
- Double or triple glazing.
- Acoustically tested.
- Enhanced thermal foam U-values of 0.74 are achievable, consult manufacturer for details.
- Seamlessly suites with Comar Systems.
General information
Color | Black Grey White Other Guidance for specification option: Other RAL colours are available on request. |
Finish | Anodized Mill Painted |
Material | Aluminium |
Length | Bespoke |
Width | 3000 mm Guidance for specification option: Maximum. |
Height | 3000 mm Guidance for specification option: Maximum. |
Warranty description | Ten year |
Uniclass | |
CAWS | L20/520 Sliding doors |
Specification data - Sliding doorset systems
Doorset | |
Type | Lift and slide double track, two panel.Lift and slide double track, three panel.Lift and slide double track, four panel.Lift and slide double track, six panel.Lift and slide triple track, two panel.Lift and slide triple track, three panel.Lift and slide triple track, four panel.Lift and slide triple track, six panel. |
Glazing | Double glazed.Triple glazed.Manufacturer guidanceGlazing thickness maximum: 57 mm. Consult manufacturer for details and insert requirements. |
Thresholds | Triple track rebated threshold.Double track rebated threshold.Low threshold. |
Hardware | Lever handle internal and external.Lever handle internal. |
System accessories | Slim interlocks.Guidance for specification option: Optional slim interlocks maximize the homeowners view out when the doors are in the closed position keeping the slim sightlines of Comar 7Pi LS+ doors with the reassurance of the lowest U-values. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Aluminium |
Recyclability | 100% at end of life |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 70 % |
Literature
Comar LS+ Data
