Application

Suitable for all heights on new and refurbishment projects, including glazed roofing applications.

Description

Comar 6EFT is an insulated curtain wall system, suitable for all heights on new and refurbishment projects, including glazed roofing applications. It has four forms of construction in one system:

  • Comar 6EFT Curtain Walling: Enables the construction of sheer high-rise as well as sloped and inclined facades. Thermally efficient with standardized 60 mm profiles; custom-made profiles are available on request.
  • Comar 6EFT 2 sided SG: Enables vertical or horizontal aluminium sightlines; the structurally glazed side is achieved with a 20 mm EPDM joint seal or silicone sealant. Both vertical and horizontal options use standard 60 mm profiles. The framed sides use standard 60 mm profiles. A bespoke finish can be achieved through using a variety of cover caps.
  • Comar 6EFT 4 sided SG: Creates a façade with no visible aluminium sight lines; the structurally glazed sides are achieved with a 20 mm EPDM joint seal or silicone sealant. (See separate product link).
  • Comar 6EFT Concealed Vent: Enables opening vents to be inserted into the facade with no additional sightlines. Vents can be side or top hung and are performance tested.

All the systems use the same basic profiles, which integrate fully.


Incorporated components:

  • The Comar 6EFT system can be used in conjunction with Comar 5 and 9 window systems and Comar 7 and 9 aluminium doors.


Performance:

Comar 6EFT has been tested to CWCT standards:

  • Air permeability: 750 Pa.
  • Watertightness: 750 Pa static.
  • Watertightness: 600 Pa dynamic.
  • Wind resistance: 2400 Pa.
  • Safety: 3600 Pa.

General information

Color

Other

Finish

Anodized

Powder-coated

Material

Aluminium

Guidance for specification option:

Aluminium alloy 6063 T5 or T6 to BS EN 755-1: 1997.

PVC

Guidance for specification option:

Thermal barrier system is achieved by means of PVC/PP extrusions.

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Ten year

Guidance for specification option:

  • Aluminium extrusions.
  • Assembly Sealants.
  • Fixing Brackets.
  • Fixing Screws.
  • Inner Gasket.
  • Outer Gasket.
  • Thermal Break.
  • Weatherseals.

30 year

Guidance for specification option:

  • Anodized finish.

25 year

Guidance for specification option:

  • Powder-coated (matt).

Other

Guidance for specification option:

  • Paint joint / seal extrusions - warranty to be agreed.

Uniclass

Ss_25_10_20_85 Stick curtain walling systemsPrimary

CAWS

H11/110 Curtain walling

Specification data - Stick curtain walling systems

Framing

-

Frame members

Aluminium curtain wall frame sections.

Frame accessories

Custom made external cover caps.

Guidance for specification option:

A variety of cover caps are available for this system. The slimmest sightlines can be achieved using a 50 mm wide cap, which is double chamfered to provide a visible face of 16 mm. Cover caps have a typical edge radius of 1.5 mm for even distribution of the powder coating layer.

Fasteners

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Cladding units

-

Glass units

Double glazed.

Triple glazed.

Manufacturer guidance

Consult with Comar for recommendations and types of glass.

Glazing accessories

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Panels and facings

-

Material

Aluminium alloy extruded profiles 6063 T5 or T6 to BS EN 755 or BS EN 12020.

Guidance for specification option:

Consult with Comar for spandrel panel recommendations and details.

System accessories

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Type

Comar 6EFT.

Comar 6EFT 2 sided SG.

Comar 6EFT Concealed Vent.

System

Vertical and horizontal caps.

Horizontal caps only.

Guidance for specification option:

2 sided structural sealant glazed.

Vertical caps only.

Guidance for specification option:

2 sided structural sealant glazed.

Finish

Anodized.

Liquid organic coating.

Polyester powder coated.

Manufacturer guidance

  • Black/ Bronze/ Silver anodizing to BS 3987.
  • Liquid organic coating to BS 4842.
  • Polyester powder coating to BS 6496.

Consult with Comar for availability of liquid organic and polyester powder coating colours.

Drainage

Guidance for specification option:

Comar 6EFT is a mullion drained system which meets the requirements of ‘ventilated and drained glazing system’ in BS 6262.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Aluminium

Guidance for specification option:

Aluminium alloy 6063 T5 or T6 to BS EN 755-1: 1997.

PVC

Guidance for specification option:

Thermal barrier system is achieved by means of PVC/PP extrusions.

Recyclability

Aluminium profile fully recyclable at end of life

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

70 %

Literature
