COM 1 Mailbox
Verified by manufacturer 5 months ago
414 mm
414 mm
The COM 1 Mailbox is a vertical mail storage solution suitable for internal and external locations.
Application
Interior and exterior applications.
Description
Vertical mailbox which is a robust and long-lasting mail solution that combines delicate design features with strong aluminium extrusion material.
The mailbox securely stores flexible A4 mail and complies with the Secured by Design Homes 2016 Guide as standard, without the need for an additional aperture restrictor.
Manufactured using zintec steel and finished with polyester powder coated paint to a choice of colours from our standard RAL colour range.
Features and benefits:
- Accepts and securely stores A4 sized mail.
- Supplied with a set of 2 keys. Master suited keys are available on request.
- Manufactured using aluminium extrusion and finished with any colour from our RAL colour range.
- Can be produced to meet specific requirements.
- Secured by design homes 2023 guide compliant.
- Royal mail compliant, BS EN 13724.
- Made in the UK.
General information
Color | Ivory Yellow Red Blue Green Manufacturer guidanceAny RAL colour from the standard colour range, contact manufacturer for details. |
Finish | Powder-coated |
Material | Aluminium |
Shape | Rectangle |
Length | 120 mm |
Width | 265 mm |
Height | 389 mm |
Warranty description | One year |
Uniclass | |
CAWS | N10/400 Mailboxes N10/96 Mailboxes |
Specification data - Letter boxes
Standard | To BS EN 13724. |
Classification grades (minimum) | |
Type of aperture | Aluminium flap, including bridge. |
Aperture size | 235 x 42 mm. |
Security | Conforms to SBD homes 2023.Guidance for specification option: Additional aperture restrictors are available, and three-point locking if required. |
Fire resistance | Class 0. |
Size | 120 x 414 x 265 mm.Guidance for specification option: Depth x Height x Width. |
Materials | Aluminium. |
Colour and finish | Polyester powder-coated, RAL.Guidance for specification option: All RAL colours are available, insert requirement. |
Integral accessories | Supplied with a set of 2 keys.Manufacturer guidanceMaster suited keys are available on request. |
Installation | Freestanding. Recessed. Wall mounted. Through the wall. With door entry system. |
Accessories | None. Aperture restrictor. Three-point locking. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | 100% |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
Literature
COM 1 Datasheet
Case studies
Bradwell Street
