H1 Lateral Mailbox

Verified by manufacturer 2 months ago

The Safety Letterbox Company

The H1 is a steel mailbox in a lateral orientation for projects where there is a limited depth space available.

Jump to:
BOS
+44 (0)1639 633525 Website

Application

Internal applications.

Description

Lateral mailbox for internal use. Suitable for wall mount, wall recess and free standing. Economy range manufactured from Zintec steel. Powder coated to a choice of colours from our standard RAL range.


Features and benefits:

  • The H1 Lateral mailbox is one of the most popular products in our range.
  • Accepts and securely stores A4 sized mail.
  • Supplied with a set of 2 keys. Master suited keys are available on request.
  • Manufactured using steel and finished with any colour from our RAL colour range.
  • Secured by design homes 2023 guide compliant.
  • Made in the UK.
  • Add on box height: 107 mm.
  • for project specific drawings please message us

General information

Color

Other

Black

Blue

Brown

Copper

Show more

Manufacturer guidance

Any RAL colour from the standard colour range, contact manufacturer for details.

Finish

Powder-coated

Material

Steel

Shape

Rectangle

Length

270 mm

Width

370 mm

Height

107 mm

Warranty description

One year

Uniclass

Pr_40_30_50_46 Letter boxesPrimary
Pr_40_30_87_48 Lockers

CAWS

N10/400 Mailboxes

N10/96 Mailboxes

Specification data - Letter boxes

Standard

To BS EN 13724.

Classification grades (minimum)

-

Type of aperture

Mailbox flap with security bridge.

Aperture size

328 x 19 mm.

Guidance for specification option:

Width x Height.

Fire resistance

Class 0.

Size

270 x 107 x 380 mm.

Guidance for specification option:

Depth x Height x Width.

Materials

Zintec steel.

Integral accessories

Supplied with a set of 2 keys.

Guidance for specification option:

Master suited keys are available on request.

Installation

Freestanding.

Recessed.

Wall mounted.

With door entry system.

Bespoke arrangement.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Steel

Recyclability

100%

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
