Clipso So Classic stretched fabric - Fabric Membrane Ceiling System

Name: Clipso So Classic stretched fabric - Fabric Membrane Ceiling System
Brand: Saint-Gobain Ecophon
SKU: aBjRGU3CeJgDsMnZKBfn3

Verified by manufacturer 7 days ago

Saint-Gobain Ecophon

Product certifications:

Indoor Air Comfort – Eurofins
Certificate type
M1 emission classification
Certificate type
EPD
Certificate type
EPD
Certificate type
European Technical Approvals
Certificate type
EU-type Examination Certificate
Certificate type

A stretched Fabric Membrane Ceiling System for walls and ceilings.

Jump to:

Request BIM

+44 (0)1256 855250 Website

Application

Suitable for both residential and non-residential areas.

Description

Ecophon Clipso So Classic 705 S Fabric Membrane Ceiling and wall System is a textile fabric with a uniform coating. The fabric is installed with Clipso profiles.

Features and benefits:

Light weight fabric installed without absorber.
Up to 5.10 m width.
Cold and dry installation with a neutral finish.

General information

Color	White Clear Beige Black Blue Bronze Brown Copper Cream Gold Green Grey Ivory Orange Pink Purple Red Silver Turquoise Yellow Other Show more
Finish	Other
Material	Fabric Guidance for specification option: Stretched fabric membrane.
Shape	Rectangle Circle Crescent Diamond Elliptical Hexagon Kite Octagon Oval Parallelogram Pentagon Rhombus Square Trapezium Trapezoid Triangle Other Show more
Length	Bespoke
Width	1500 mm 2000 mm 2500 mm 3000 mm 3200 mm 3500 mm 4000 mm 4500 mm 5100 mm Show more
Height	0.3 mm
Warranty description	Ten year Manufacturer guidance All Ecophon installations can be warranted for ten years.

Uniclass	Ss_30_25_22_30 Fabric membrane ceiling systemsPrimary
CAWS	H90/140 Internal single-layer fabric system

SKU Code	Clipso So Classic stretched fabric

Specification data - Fabric membrane ceiling systems

Classification data
Ceiling support	Clipso PCW profiles. Clipso PCC profiles.
Ceiling fabric	So Classic 705 S. Guidance for specification option: Stretched fabric membrane.
Samples required	- Manufacturer guidance Insert requirements or omit.
Indoor climate	Eurofins Indoor Air Comfort® IAC Gold. Certified as A+ by French VOC. Greenguard Gold.
Fire safety	To EN 13501-1, Class B-s1,d0. Guidance for specification option: International Maritime Organisation, Resolutions MSC.307(88) and MSC.61(67), Modules B and D.
Moisture resistance	Dimensional stability under the action of humidity: To EN 14716 (Appendix C), 0% (MD/CMD). Dimensional stability under the action of heat: EN 12280-1 (30 minutes, 60°C), 0% (MD/CMD). Water vapour transmission rate: To ISO 2528 (38°C, 90% RH), 1184 g/m².
Colour/ Finish	Optical white, matt, smooth and uniform. Guidance for specification option: Nearest colour sample RAL 9016.
Width	1500 mm. 2000 mm. 2500 mm. 3000 mm. 3200 mm. 3500 mm. 4000 mm. 4500 mm. 5100 mm.
TensileStrength	To ISO 1421: 28 daN/5 cm (MD), 62 daN/5 cm (CMD).
Tear strength	To EN 1875-3: 3.7 daN (MD), 6.0 daN (CMD).

Sustainability data

Contains Red List materials	No
Country of material origin	France
Country of product manufacture	France
Material	Fabric Guidance for specification option: Stretched fabric membrane.
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 2.27 Manufacturer guidance Life-cycle stages A1 to C4 from EPD, in conformity with ISO 14025/ EN 15804.
Recyclability	0
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
Expected Life	50 year
