Chromatics Interior Cladding

Chromatics Interior Cladding

Third party certifications:
  • CWCT Certificate

    CWCT Certificate

    Certificate type

Chromatics Glass Ltd

Lightweight, shatterproof, bacteria-resistant interior safety glass panel, available in any colour or HD digital print.

Jump to:
+44 (0)1904 439187 www.chromaticsglass.com
Application

Suitable for use in interiors where safety, hygiene, easy maintenance and aesthetics are required. For example:

  • Airports.
  • Stations.
  • Schools.
  • Retail outlets.
  • Hotels.
  • Lifts and escalators (product is resistant to damage caused by vibration).
  • Public spaces.
  • Security (including Government and Military buildings).
  • Clean rooms.
  • Medical facilities.
  • Catering areas.
  • Partitions, wall cladding and linings.
  • Feature walls.
  • Balustrades.
  • Wayfinding and signage.

Description

Lightweight, bacteria-resistant interior laminated panel, comprising 6 mm safety glass as standard with an opaque colour or print layer and aluminium backing. The panel can be structurally bonded, or installed using traditional glazing or cladding systems.

Can be specified to BS EN 12600 3(B)3 or to BS EN 12600 1(B)1. The product is rated A2-s1, d0 in reaction to fire performance to EN 13501-1: 2007 and A1: 2009.

Features and benefits:

  • Certified to EN 1542:1999: Integrity of laminates.
  • Half the weight of traditional laminated or toughened glass.
  • Shatterproof; if broken, the panel will remain safe and intact.
  • Any colour and/ or HD digital print is available, and the panels can be colour matched to corporate colours.
  • Wayfinding and signage can be incorporated in and across panels.
  • Specified and installed by BAA and Network Rail.
  • Bomb blast tested by UK and Italian Ministry of Defence (MOD) with repeated explosions up to 1800 kg explosives.
  • Can be easily cut using standard glass industry cutting equipment, including manual and water-jet cutting.
  • Can be drilled, edge-worked, and notched using standard glass industry techniques.
  • Available as security cladding (which is bomb blast resistant).
  • Invisible fix with no show-through of adhesive, and certified for use with structural adhesives.
  • Can be installed using fast-track of clip up/ down fixing systems – consult manufacturer for details.
  • Can be bonded to most carrier boards/ panels or rails.
  • UV stable.
  • No rollerwave; panels are extremely flat.
  • Can be configured to any orientation.
  • No pin-holes.
  • Highly reflective, 100% opaque finish.
  • Highly durable, UV stable and retains appearance and performance for years.
  • Easy to maintain, and can be quickly installed.
  • Acts as a barrier for electronic surveillance, helping to increase privacy.
  • Low energy and low environmental impact.
  • No heavy metals or toxic elements, solvent-free, and will not produce any volatile organic compounds (VOCs).
  • Manufactured from renewable and recyclable materials.
  • Impervious to attack from the rear by adhesives and solvents. Approved for fixing with Sika and Dow Corning structural adhesives.
  • Has a life expectancy of more than 25 years.

Applications:

Suitable for use in interiors where safety, hygiene, easy maintenance and aesthetics are required. For example:

  • Airports.
  • Stations.
  • Schools.
  • Retail outlets.
  • Hotels.
  • Lifts and escalators (product is resistant to damage caused by vibration).
  • Public spaces.
  • Security (including Government and Military buildings).
  • Clean rooms.
  • Medical facilities.
  • Catering areas.
  • Partitions, wall cladding and linings.
  • Feature walls.
  • Balustrades.
  • Wayfinding and signage.

General information
Size

3100 x 2500 mm (maximum finished panel size). Other sizes are available on request, consult manufacturer for details.

Uniclass 2015
Pr_25_71_33_14 Composite glass sheetsPrimary
CAWS

K13/160 Proprietary

Specification data - Composite glass sheets
Product Reference

Chromatics Interior Cladding

Glass type

Clear float

Low iron

Self-cleaning

On request.

Thickness

Consult manufacturer for details and insert requirements. 6 mm standard thickness.

Size

3100 x 2500 mm (maximum finished panel size). Other sizes are available on request, consult manufacturer for details.

Impact resistance (to BS EN 12600)

Class 1(B)1

Class 3(B)3

Colour/ Finish

Colour layer

Available in any RAL design or RAL classic colour, consult manufacturer and insert requirement.

Print layer

Digital images can be used - consult manufacturer and insert drawing/ reference.

Standard product features

Weight:

6 mm panel: 15 kg/m².

Edge profile:

Polished and arrised.

Technical characteristics:

  • Fire rating (to EN13501-1: 2007 and A1: 2009): A2-s1,d0.
  • Impact resistance : To BS EN 12600 3(B)3 or to BS EN 12600 1(B)1.
  • Laminate integrity (to BS EN 1542: 1999): Pull-off tests exceeded.
  • Light transmittance: 0.

Product Options

Size:

Supplied to required size as finished panels - maximum 3100 x 2500 mm. Other sizes may be available, consult manufacturer for details.

Colour/ Finish:

- Colour layer:

Any RAL classic colour available. For other colours, consult manufacturer.

- Print layer:

Digital images can be reproduced to full panel size or tiled over any number of panels. It is encapsulated between the glass and aluminium and is therefore protected from moisture, solvents, salts and other volatiles. Consult manufacturer for details.

Third party certifications
  • Certified N950/10/16177A. : Standard for systemised building envelopes
