Cheddar Red

Verified by manufacturer 3 months ago

Ibstock Brick Ltd

Smooth facing brick. Manufactured to BS EN 771-1.

Jump to:
BOS
+44 (0)1530 261999 Website

Application

Brick laying applications.

Description

Smooth facing brick. Manufactured to BS EN 771-1.


Features and benefits:

  • Brick k-value: 1.24.
  • Brick voids: 25–30%.

General information

Color

Red

Finish

Smooth

Material

Clay

Shape

Rectangle

Length

215 mm

Width

102 mm

Height

65 mm

Uniclass

Pr_20_93_52_15 Clay bricksPrimary

CAWS

Q10/130 Clay brick

Q10/20 Clay brick

F10/110 Clay facing brickwork

Specification data - Clay bricks

Standard

To BS EN 771-1.

Brick description

Facing brick.

Work size (length x width x height)

215 x 102 x 65 mm.

Tolerances

-

Mean value

T2.

Range

R1.

Compressive strength

-

Mean compressive strength (minimum)

75.

Durability designation

F2.

Density

-

Gross dry

1750 kg/m³.

Net dry

2370 kg/m³.

Tolerance

T2.

Water absorption

7%.

Configuration

Vertically perforated.

Thermal conductivity

1.24 W/mK.

Water vapour permeability

50/100 µ.

Bond strength

0.15 N/mm².

Reaction to fire

A1.

Weight

2.3 kg.

Pack

500.

Guidance for specification option:

Quantity.

Active soluble salts

S2.

Density

1750.

Type

Wirecut.

Configuration

Vertically perforated.

Package

Banded (plastic) & shrinkwrapped.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
