Cemgold Fibre Cement Building Board
Compare variants

Application

Suitable for use in :

  • Offsite construction;
  • Wet areas;
  • Façades;
  • Renders;
  • Rainscreen cladding;
  • Soffits;
  • Eaves lining.
  • Sign boards;
  • Drylining;
  • Roofing.
  • Timber frame.

Description

A 100% asbestos free fibre cement board, made from a homogeneous Portland cement and high purity silica sand with reinforcing fibre or pulp added using pressing and autoclave processes.


Cemgold is a very strong and durable board with superior physical and mechanical properties, and offers fantastic racking performance tested with Lucideon in Stoke on Trent making it the ideal board for timber frame construction and off site construction.


Features and benefits:

  • High impact resistance.
  • Very good acoustic properties.
  • Durable.
  • High manufacturing tolerances.
  • Available in a range of thicknesses.
  • For off-site, modular and linings for rainscreen cladding projects.
  • Can be used as an external sheathing board in structures under 18 m in height and behind many different types of façade.

General information

Finish

Smooth

Smooth surface with particulate core

Material

Cement

Portland cement, high purity silica sand and cellulose reinforcing fibres.

Portland cement

Silica sand

Sand

Cellulose fibres

Shape

Rectangular

Size

1200 x 2400 x 10 mm

1200 x 2400 x 12.5 mm

1200 x 2400 x 16 mm

1200 x 2400 x 18 mm

Uniclass 2015

Pr_25_71_11_29 Fibre-reinforced cement sheetsPrimary

CAWS

G20/950 Fascias/ barges/ soffits

G20/99 Fascias/ barges/ soffits

H20/10 Sheet cladding

H20/150 Sheet cladding

H20/155 Sheet cladding

K11/145 Battened cement-bonded particleboard floating floor

K11/245 Cement bonded particleboard floating floor

K11/345 Cement-bonded particleboard flooring

K11/60 Board

K11/795 Wall lining on metal framing

K11/845 Cement-bonded particleboard

K11/890 Board

K40/10 Unit/ modular suspended ceilings

K40/270 Boards

K45/350 Boards

U90/425 Rigid ductwork and fittings

U90/425 Rigid ductwork and fittings

Specification data - Fibre-reinforced cement sheets Enhanced data

Material

-

Standard

To BS EN 12467.

Type

Portland cement, high purity silica sand and cellulose reinforcing fibres.

Fire performance

-

Reaction to fire class

To BS EN 13501-1, Class A1.

Non-Combustible.

Non-standard requirements

To BS 476, Class 0 part 6 and 7.

Weather resistance

Freeze/ thaw resistant, and water-resistant.

Panel thickness

10 mm.

Panel size

1200 x 2400 mm.

Edge profile

Square.

Finish as delivered

Smooth surface with particulate core.

Product Reference

Cemgold Fibre Cement Building Board

AcousticRating

To BS EN 12467, 30–64 db.

Density

To BS EN 12467, 1300 kg/m³.

MoistureContent

To BS EN 12467, 5—10%.

ThicknessSwelling

<2%.

ThermalConductivity

To BS EN 12467, 0.15 W/m²K.

Dimensional tolerances

Length: ±2 mm; width ±2 mm.

Watertightness

To BS EN 12467, Pass.

Moisture movement

To BS EN 12467, 0.06—0.11%.

pH value

To BS EN 12467, 7—10.

Weight

38 kg.

Environmental information

Recyclability

Fully Recyclable

Recycled content

100

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
