Cembrit Solid - Facade Panel

Verified by manufacturer 11 months ago

Swisspearl

'A' fire rated, intensely pigmented acrylic coated fibre cement rainscreen façade panel.

Jump to:
BIM object icon
+44 (0)203 3722300 Website

Application

Suitable for use as rainscreen cladding, rigid sheet cladding and soffits.

Description

A non-combustible, intensely pigmented, acrylic-coated fibre cement rainscreen cladding board.


Features and benefits:

  • Through-coloured.
  • Made to order special colours.
  • Disguises surface damage.
  • Intense colours.

General information

Color

Choice of 18 colours.

Other

Material

Fibre cement

Shape

Rectangle

Length

2500 mm

3050 mm

Width

1250 mm

Height

8 mm

Uniclass

Pr_25_71_11_25 Fibre-reinforced cement boardsPrimary

CAWS

G20/950 Fascias/ barges/ soffits

G20/99 Fascias/ barges/ soffits

H20/150 Sheet cladding (attached to metal support systems)

H20/155 Sheet cladding (attached to timber battens)

H92/120 Rainscreen cladding

Product range

Cladding Boards

Specification data - Fibre-reinforced cement boards

Standard

To BS EN 12467:2004, Class NT A41.

Fire rating

To BS EN 13501-1, Class A2-s1, d0.

Sheet size

-

Nominal thickness

8 mm.

Length

2500 mm.

3050 mm.

Width

1250 mm.

Edges

Colour on every surface and edge.

Finish as delivered

Acrylic coated, smooth surface.

Colour

S030-Solid Mercury.

S071-Solid Orcus.

S101-Solid Pluto.

S131-Solid Deep Black.

S151-Solid RAL 7016.

S191-Solid Erebus.

S212-Solid Luna.

S282-Solid Saturn.

S334-Solid Jupiter.

S353-Solid Mars.

S515-Solid Venus.

S525-Solid Triton.

S606-Solid Rhea.

S616-Solid Ceres.

S656-Solid Terra.

S676-Solid Callisto.

S747-Solid Neptune.

S757-Solid Mimas.

Special order.

Insert requirement.

Product Reference

Cembrit Solid

Weight

14.2 kg/m².

Treatment

Air cured.

Fixing method

Rivet, screw, site bonding or mechanical secret fix (MSF).

Sustainability data

Contains Red List materials

No

Country of product manufacture

Hungary

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

Guidance:

Per tonne:

  • Global warming potential (GWP): 1.79E+03 kg CO2-eq.
  • Ozone depletion potential: 6.84E-07 kg CFC11-eq.
  • Acidification potential of soil and water: 4.46E+00 kg SO2-eq.
  • Eutrophication potential: 4.97E-01 kg PO43-eq.
  • Photochemical ozone creation potential: 7.81E-01 kg ethene-eq.
  • Abiotic depletion potential for non-fossil resources: 3.64E-02 kg Sb-eq.
  • Abiotic depletion potential for fossil resources: 2.08E+04 MJ.

16.5 kg CO₂ eq/m²

Recycled content

  • Use of renewable primary energy excluding renewable primary energy resources used as raw materials: 2.64E+03 MJ.
  • Use of renewable primary energy resources used as raw materials: 1.07E+03 MJ.
  • Total use of renewable primary energy resources: 3.71E+03 MJ.
  • Use of non-renewable primary energy excluding non-renewable primary energy resources used as raw materials: 2.28E+04 MJ.
  • Use of non-renewable primary energy resources used as raw materials: 1.51E+03 MJ.
  • Total use of non-renewable primary energy resources: 2.43E+04 MJ.
  • Use of renewable secondary fuels: 5.61E-06 MJ.
  • Use of non-renewable secondary fuels: 5.16E-05 MJ.
  • Use of net fresh water: 7.32E+00 m³.

-
