Cembrit Cover - Facade Panel

Verified by manufacturer 6 months ago

Swisspearl

'A' fire rated fibre cement coated decorative rainscreen façade board.

Jump to:
BOS
 +44 (0)203 3722300 Website

Application

Suitable for use as rainscreen cladding, rigid sheet cladding and soffits.

Description

A non-combustible coated decorative rainscreen cladding board featuring a natural grey fibre cement core surface painted with a layer of water-based acrylic paint.


Features and benefits:

  • 26 standard colour choices.
  • Over 2000 NCS®© special order colours.

General information

Color

Other

Manufacturer guidance

  • Choice of 26 standard colours.
  • Special colours available.

Finish

Coated

Material

Fibre cement

Shape

Square

Length

1192 mm

2392 mm

2500 mm

2992 mm

3050 mm

Width

292 mm

592 mm

1192 mm

1250 mm

Height

8 mm

Uniclass

Pr_25_71_11_25 Fibre-reinforced cement boardsPrimary

CAWS

G20/950 Fascias/ barges/ soffits

G20/99 Fascias/ barges/ soffits

H20/150 Sheet cladding (attached to metal support systems)

H20/155 Sheet cladding (attached to timber battens)

H92/120 Rainscreen cladding

Product range

Cladding Boards

Specification data - Fibre-reinforced cement boards

Standard

To BS EN 12467:2004, Class NT A41.

Fire rating

To BS EN 13501-1, Class A2-s1, d0.

Sheet size

-

Nominal thickness

8 mm.

Length

2500 mm.

3050 mm.

Width

1250 mm.

Edges

Square.

Finish as delivered

Coated.

Colour

C010-Cover Stockholm.

C020-Cover Vilnius.

C040-Cover Sofia.

C050-Cover Berlin.

C060-Cover Helsinki.

C160-Cover London.

C210-Cover Nuuk.

C300-Cover Milan.

C360-Cover Copenhagen.

C380-Cover Lyon.

C390-Cover Istanbul.

C450-Cover Amsterdam.

C530-Cover Rome.

C540-Cover Kiev.

C550-Cover Athens.

C560-Cover Bonn.

C570-Cover Barcelona.

C600-Cover Prague.

C610-Cover Lisbon.

C630-Cover Geneva.

C640-Cover Hamburg.

C650-Cover Madrid.

C670-Cover Dublin.

C730-Cover Oslo.

C760-Cover Naples.

C770-Cover Riga.

Special order.

Guidance for specification option:

Insert requirement.

Product Reference

Cembrit Cover

Weight

14.2 kg/m².

Treatment

Air cured.

Fixing method

Rivet, screw, site bonding or mechanical secret fix (MSF).

Sustainability data

Contains Red List materials

No

Country of product manufacture

Hungary

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

16.5 kg CO₂ eq/m²

Self declared

Manufacturer guidance

Per tonne:

  • Global warming potential (GWP): 1.76E+03 kg CO2-eq.
  • Ozone depletion potential: 6.84E-07 kg CFC11-eq.
  • Acidification potential of soil and water: 4.38E+00 kg SO2-eq.
  • Eutrophication potential: 4.89E-01 kg PO43-eq.
  • Photochemical ozone creation potential: 7.72E-01 kg ethene-eq.
  • Abiotic depletion potential for non-fossil resources: 3.64E-02 kg Sb-eq.
  • Abiotic depletion potential for fossil resources: 2.06E+04 MJ.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

-

Manufacturer guidance

  • Use of renewable primary energy excluding renewable primary energy resources used as raw materials: 2.63E+03 MJ.
  • Use of renewable primary energy resources used as raw materials: 1.07E+03 MJ.
  • Total use of renewable primary energy resources: 3.70E+03 MJ.
  • Use of non-renewable primary energy excluding non-renewable primary energy resources used as raw materials: 2.25E+04 MJ.
  • Use of non-renewable primary energy resources used as raw materials: 1.51E+03 MJ.
  • Total use of non-renewable primary energy resources: 2.41E+04 MJ.
  • Use of renewable secondary fuels: 5.61E-06 MJ.
  • Use of non-renewable secondary fuels: 5.16E-05 MJ.
  • Use of net fresh water: 7.28E+00 m³.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
 -

1

IFC
 -

1

Literature

Cembrit Patina, Cover, Solid & Transparent - Cladding

Cembrit Patina, Cover, Solid & Transparent - Cladding

Cembrit Cover & Solid Colours

Cembrit Cover & Solid Colours
