Robust, automatic flood pump system for cellar floor or sump.
For residential and smaller commercial properties.
Andel CellarGuard® is an automatic flood pump system that provides protection for properties at risk of flooding. The system uses conductive probes to detect floodwater rather than float switches which benefits its reliability.
Andel CellarGuard® comprises a wall-mounted control unit that can be installed at a convenient, accessible location and a stainless steel pump and sensor unit designed for a cellar, basement floor or a shallow sump.
The pump can pump down to a depth of 10 mm of flood water on a flat surface or in a shallow sump, the unit is also fully submersible.
Features and benefits:
Color | Silver Black |
Material | Stainless steel Guidance for specification option: Pump and chamber. Acrylonitrile butadiene styrene (ABS) Guidance for specification option: Control panel. |
Shape | Other |
Length | 111 mm Guidance for specification option: Control panel depth. |
Width | 180 mm Guidance for specification option: Control panel width. |
Height | 110 mm Guidance for specification option: Control panel height. |
Warranty description | Ten year |
Material | Stainless steel Guidance for specification option: Pump and chamber. Acrylonitrile butadiene styrene (ABS) Guidance for specification option: Control panel. |
Uniclass | |
CAWS | R12/135 Private packaged pumping stations and pressure pipeline system R18/310 Package pumping stations |
Collection tank | |
Material | Stainless steel. |
Type | Horizontal. |
Pumps | |
Configuration | Single pump, with chamber space. |
Pump characteristic | Stainless steel pump.Guidance for specification option:
|
Non-return valve | Required.Not required. |
Control | ABS, IP66 rated.Guidance for specification option:
|
Integral accessories | 10 m pump cable. |
LED Colour | Red LED (pump running). |
Sensor | 3 x conductivity probes. |
Accessories | Not required. Mains cables. Guidance for specification option: Contact manufacturer for details. Discharge hoses. Guidance for specification option: Contact manufacturer for details. Large capacity pump. Guidance for specification option: Contact manufacturer for details. |
Power supply | 230 V a.c.; 50/60 Hz. |
Fuse rating | 3 A. |
Material | Stainless steel Guidance for specification option: Pump and chamber. Acrylonitrile butadiene styrene (ABS) Guidance for specification option: Control panel. |
