Application

CASEA Sudanit 230 Screed is suitable for floors in homes, offices, public buildings and places exposed to similar loads. It may be applied as a levelling screed directly onto a load bearing floor, unbonded on a separating barrier (polythene) or as a floating floor and is particularly suited in conjunction with underfloor heating or cavity floors. It should be covered with a floor finish such as tiles, linoleum, parquet, cork or carpet. If a cement based adhesive or smoothing compound is required, the surface of the screed must first be sealed, using an appropriate acrylic primer/ sealer.

Description

Südanit 230 Alpha Hemihydrate Binder is a specially formulated calcium sulfate binder suitable for the production of top quality self levelling (flowing) floor screeds, simply by blending with a suitable sand and water on site. Südanit 230 Alpha Hemihydrate Binder complies with EN 13454-1:2004 and is CE marked.

Benefits:

  • Smooth laitance free finish.
  • Pumpable.
  • Underfloor heating – full encapsulation.
  • Suitable for underlayment in wet areas.
  • Reduced drying times.
  • CE marked.
  • BS EN 13454-1.

Applications:

CASEA Sudanit 230 Screed is suitable for floors in homes, offices, public buildings and places exposed to similar loads. It may be applied as a levelling screed directly onto a load bearing floor, unbonded on a separating barrier (polythene) or as a floating floor and is particularly suited in conjunction with underfloor heating or cavity floors. It should be covered with a floor finish such as tiles, linoleum, parquet, cork or carpet. If a cement based adhesive or smoothing compound is required, the surface of the screed must first be sealed, using an appropriate acrylic primer/ sealer.

General information
Specification data - Ready-mixed self-smoothing calcium sulfate screeds
Product Reference

CASEA Sudanit 230 Binder

Designation

CAB30

Standard product features

Technical characteristics (to EN 13813: 2002):

  • Maximum thickness: 90 mm.
  • Minimum thickness: Bonded, 20 mm. Unbonded, 30 mm. Domestic, 35 mm. Commercial, 40 mm. Over underfloor heating pipes: 25 mm (BS 8204-7).
  • Use: Internal.
  • Compressive strength (28 days): >25 N/mm², >30 N/mm², >40 N/mm².
  • Flexural strength (28 days): > 5 N/mm², > 6 N/mm², > 7 N/mm².
  • Tensile adhesion: > 1.5 N/mm².
  • Shrinkage (28 days): < 0.1%.
  • Hardening time (before foot traffic): approx 12 hours.
  • Recommend water content: 14–16%.
  • Reaction to fire: A1 non-combustible.
  • Thermal conductivity: 1.6 W/mK.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2017 1 2.1
IFC
- 1 2.1
Download now from NBS National BIM Library
