Application

Casufloor AB 30 Screed is suitable for floors in homes, offices, public buildings and places exposed to similar loads. It may be applied in accordance with DIN 18560, directly onto a load bearing floor, unbonded on a separating barrier (polythene) or as a floating floor and is suited in conjunction with underfloor heating. It should be covered with a floor finish such as tiles, linoleum, parquet, cork or carpet. If a cement based adhesive or smoothing compound is required the surface of the screed must first be sealed using an appropriate acrylic primer/ sealer.

Description

CASEA Casufloor AB 30 – Semi Dry Screed Binder is a specially formulated natural calcium sulfate binder suitable for the production of top quality semi-dry floor screeds, simply by blending with suitable sand and water on site. Casufloor AB 30 complies with BS EN 13454-1 and is CE marked.

Benefits:

  • Designation: CA-C20-F4 or CA-C30-F6.
  • Very low shrinkage.
  • Reduced drying times.
  • CE marked.

Applications:

Casufloor AB 30 Screed is suitable for floors in homes, offices, public buildings and places exposed to similar loads. It may be applied in accordance with DIN 18560, directly onto a load bearing floor, unbonded on a separating barrier (polythene) or as a floating floor and is suited in conjunction with underfloor heating. It should be covered with a floor finish such as tiles, linoleum, parquet, cork or carpet. If a cement based adhesive or smoothing compound is required the surface of the screed must first be sealed using an appropriate acrylic primer/ sealer.

General information
Specification data - Ready-mixed self-smoothing calcium sulfate screeds
Product Reference

CASEA Casufloor AB 30

Type

C20/F4

C30/F6

Standard product features

Application/ Thickness:

  • Bonded: > 15–50 mm.
  • Unbonded: > 30 mm.
  • Floating: > 45 mm (C20-F4); > 40 mm (C30-F6).
  • Underfloor heating: > 45 mm (C20-F4); > 40 mm (C30-F6).

Product Options

Technical characteristics (to EN 13813: 2002):

  • Compressive strength: C20/ C30.
  • Flexural strength: F4/ F6.
  • Reaction to fire: A1 non-combustible.
  • Thermal conductivity: λR = 1.30 W/mK.
  • Yield: 75 kg mixed with 280 kg sand (C20-F4) – 27%.
  • 100 kg mixed with 250 kg sand (C30-F6) – 40%.

Digital objects
PlatformCompatibleVersionCertified to
IFC
IFC2X3 5 1.3
Vectorworks
- 1.0
AECOsim
- 1.0
ARCHICAD
- 1.0
Revit
Revit 2016 6 2.0
Download now from NBS National BIM Library
