CASEA Bauprotec 900 E - Lime render

Application

Suitable for façades and walls constructed out of low, medium and high density blockwork or any other masonry substrate.

Description

A factory produced lightweight lime cement render specially designed for hand and machine application produced to BS EN 998-1. It is manufactured from a controlled blend of selected aggregates, lightweight aggregates, cement, polymers, fibres and other components to give a high quality weather resistant rendering product which is suitable for use in external rendering and internal plastering. The product’s special composition allows the product to breathe and also permits constant hygrometric exchange between the substrate and the environment.


Features and benefits:

  • Lightweight – low tension.
  • High yield.
  • Weather resistant.
  • CE marked.
  • BS EN 998-1.

General information

Uniclass 2015

Pr_35_31_64_65 Polymer-modified rendersPrimary

CAWS

M20/160 Proprietary cement gauged render

M20/19 Proprietary cement gauged render

Product range

Renders

Specification data - Polymer-modified renders Enhanced data

Dry density

Dry Bulk Density

1000 kg/m³.

CompressiveStrength

>3.0 N/mm² CS II.

Flexural strength

1.2 N/mm² (approximately).

Modulus of elasticity

ca. 2.5 kN/mm².

Capillary absorption

Capillary Water Absorption

W 2 as per DIN EN 998.

Adhesion

≥0.08 N/mm² FP A,B or C.

Water vapour permeability

μ ≤20.

ThermalConductivity

(Tabular Value)

λ10, dry,mat ≤0.25 W/(mK) at P=50%.

Yield - Lime render

1.1 kg/mm/m².

WaterConsumption

Water Demand

7 L per 30 kg bag.

Digital objects

Platform Compatible Version Certified to
IFC

IFC2X3

5

1.3
ARCHICAD
-

1.0

1.0

Vectorworks
-

1.0

1.0

AECOsim
-

1.0

1.0

Revit

Revit 2016

6

2.0
Download now from NBS National BIM Library
