C5 Coated Suspension Profiles - Corrosion Resistant Profiles
Verified by manufacturer 7 months ago
Coated profiles designed to meet the requirements for the suspension and support of boards in high humidity areas such as swimming pools and wet rooms.
Application
Coated profiles designed to meet the requirements for the suspension and support of boards in high humidity areas such as swimming pools and wet rooms.
ISO 12944 classification C5: Industrial areas with high humidity and aggressive atmospheres.
Description
Coated profiles designed to meet the requirements for the suspension and support of boards in high humidity areas such as swimming pools and wet rooms.
C5 coating meets with the requirements of ISO 12944 and provides a high level of anti-corrosion resistance.
A comprehensive range of C5 coated drywall profiles for partitions, wall lining and bespoke applications are also available; consult manufacturer for details.
General information
Color | Silver Black Guidance for specification option: Requires optional spray paint. |
Finish | Galvanized |
Material | Carbon steel |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | K10/220 Proprietary suspended ceiling system K10/50 Suspended ceiling system on metal framing |
Specification data - Carbon steel dry lining frames
Material | Galvanized steel. |
Component types | |
Ceilings and soffits | C5 C ceiling profiles, 60 x 0.6 mm.C5 U perimeter profiles.C5 top hat profiles, 10 x 15 x 80 mm.C5 UA50 profiles.Manufacturer guidanceSee also Connectors and Accessories below. Consult manufacturer for further details. |
Ceiling hangers | C5 direct fix hangers, 125 mm.C5 direct fix hangers, 200 mm.C5 CD Nonius hangers.C5 click fix profile clips.C5 CD direct fix adjustable hangers.C5 hangers, 190 mm.Manufacturer guidanceSee Accessories below. Consult manufacturer for further details. |
Connectors | C5 profile connectors. C5 cross connectors. C5 safety cross connectors. C5 quick cross connectors. Guidance for specification option: For use with UA50 profile. |
Fixings | C5 jack point pan head screws, 13 x 4.2 mm. C5 pan head screws, 13 x 4.2 mm. C5 self-drilling screws, 19 x 6.3 mm. C5 ceiling dowels with nail head, 44 x 6 mm. |
Accessories | C5 adjusting clamps. C5 adjusting strips for Nonius hangers. Guidance for specification option: Insert requirements. Available in various lengths (100–1000 mm in 100 mm increments; 1.2, 1.4, 1.7, 2.0 and 2.5 m). C5 spray paint, black. |
