Description

Thermally modified British ash decking, produced from British grown ash logs. Brimstone ash is relatively knot free and even in colour, offering a clean and contemporary appearance. Thermal modification results in superior levels of stability and durability. Brimstone ash decking is a locally sourced alternative to tropical hardwood decks such as Ipe and Balau.. Grown in Great Britain. GIB third party certified.

General information
Color

Consistant dark chocolate brown colouring

Features

Durable, stable, consistent weathering, chemical free, grown in Britain

Finish

Machined smooth

Material

Thermally modified ash

Shape

Deck profile

Size

21 x 95 mm

21 x 120 mm

21 x 140 mm

27 x 140 mm

WarrantyDescription

None

Uniclass 2015
Modified wood boards (Pr_25_71_97_54)Primary
Specification data - Modified wood boards
Product Reference

Brimstone Ash Modified Hardwood Decking

Profile

VDEC1

21 mm thickness.

VDEC2

21 mm thickness.

VDEC3

21 mm thickness.

VDEC4

27 mm thickness.

Width

95 mm

VDEC2, VDEC3.

120 mm

VDEC2 only.

140 mm

VDEC1, VDEC2 or VDEC3.

Standard product features

Length:

Random lengths of 1.5-3.0 m, allowing a small percentage down to 1.5 m. Lengths of over 3.0 m may be included but are not guaranteed.

Appearance:

Consistent dark chocolate brown colouring with a clearly defined grain pattern. The colour can be further enhanced by the application of a clear oil such as Osmo UV-resistant oil. Relatively knot free. It weathers to a silver grey colour more quickly than non-modified timber. Small surface cracks may appear during dry periods.

Technical properties:

  • Moisture content: 4-6%.
  • Natural durability (to BS EN 350-2): Durable, Class 1.
  • Insect attack: Thermally modified wood is resistant to insect attack when used above ground contact.
  • Service life (to BS 8417): Frequently wet: 30 years (heavily reliant on good design and installation, realistic service life of 15–20 years).
  • Treatability class: Resistant.
  • Movement class: Small.
  • Resistance to impact: Medium to high.
  • Resistance to fixing: High, modified wood is brittle and should be treated with care.
  • When to fix: No restrictions.
  • Grading: BS 1186-3: Class 1; BS EN 942: J20; CE: Grade A.
  • Working properties: Thermally modified woods are more brittle than untreated wood. Care should be taken when cutting and nailing to prevent chipping and break-out; pre-drilling is advised.
  • Extractives: The modification process involves no chemicals, and any natural chemicals in the wood are removed during the process. Thermally modified wood can be treated as inert.
  • Emission of formaldehyde (to BS EN 14915): E1 (not significant).
  • Reaction to fire (to BS EN 14915): Euroclass F (untested), D-s2, d0.
  • Fire treatment: Untested.

Product Options

Fixing:

Face fixed with stainless steel screws, or with a secret fixing system such as Sihga DielenFix. Secret fixing systems that require edge grooves are not recommended. Continuous edge grooves will result in a weak edge that may snap off.

Anti-slip:

Available with two or three Gripdeck anti-slip inserts.

Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.0
Revit
Revit 2017 1 2.0
Download now from NBS National BIM Library
