Blast Resistant Steel Doors AD50 Armourdoor

Verified by manufacturer 18 days ago

HAG Ltd. - The Door Specialists Third party certifications:
  • ADSA

    ADSA

    Certificate type

  • Alcumus SafeContractor

    Alcumus SafeContractor

    Certificate type

  • Made in Britain

    Made in Britain

    Certificate type

  • CHAS

    CHAS

    Certificate type

  • Constructionline

    Constructionline

    Certificate type

  • dhf certificate

    dhf certificate

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

A high security manually operated blast resistant steel door, for commercial and industrial applications to protect against explosions. Tested to BS EN 13124-2 (EXR2 & EXR3)

Jump to:
BOS
0800 072 3444 Website

Application

Blast resistant steel door suitable for industrial, commercial, public buildings, and cultural or historical settings

  • Airports
  • Train stations
  • Warehouse
  • Factories
  • Chemical plant
  • Hospitals
  • Police stations
  • Government buildings
  • Banks
  • Museums
  • Historical sites


Description

Blast resistant steel door constructed from 1.5 mm zinc protected steel sheets and joined together in a bonding process with a solid timber core. The door frame is manufactured from 1.6 mm profiled zinc protected steel.


Features and benefits:

  • Specifically designed to be a blast resistant steel door.
  • Tested to withstand up to a 12 kg charge detonated 5.5 m away from the door.
  • Tested to BS EN 13124-2 (EXR2 & EXR3), with manual operation and triple point sash lock for additional security.
  • High security triple point sash lock with high security cylinders and are protected to reduce risk of key copying.
  • Leaf thickness of 50 mm and an infill composed of solid timber with integral steel stiffeners.
  • Door frame constructed from folded 1.6 mm Magnelis steel and fitted with dog bolts.
  • The blast door is supplied with a variable sub frame to allow up to 30 mm tolerance for site installations.
  • The door is supplied with a standard 15 mm rebated threshold and driveable thresholds available on request.
  • The door blade is fitted with an anti-jemmy as integral.
  • Can be specified to the PAS24 standard, upon request.

General information

Color

Silver

Other

Guidance for specification option:

500 RAL and BS colours available.

Finish

Textured

Guidance for specification option:

Wood grain.

Powder-coated

Guidance for specification option:

Polyester powder-coated (PPC).

Material

Steel

Guidance for specification option:

1.6 mm-thick Zintec/ Aluzinc steel.

Laminate

Stainless steel

Shape

Rectangle

Length

Bespoke

Width

690 mm

1290 mm

1390 mm

2600 mm

Manufacturer guidance

Available size range, consult manufacturer for details.

  • Single openings: 690–1390 mm.
  • Double openings: 1290–2600 mm.

Height

2900 mm

Warranty description

One year

Material

Steel

Guidance for specification option:

1.6 mm-thick Zintec/ Aluzinc steel.

Laminate

Stainless steel

Uniclass

Pr_30_59_24_52 Carbon steel doorsetsPrimary

CAWS

L20/480 Doorsets

L20/55 Doorsets

Product range

Armourdoor - Steel Doors

Specification data - Carbon steel doorsets

Configuration

Single leaf, single action.

Double leaf, single action.

Doorset size

-

Manufacturer guidance

Insert requirements:

  • Single openings width: 690–1390 mm.
  • Double openings width: 1290–2600 mm.
  • All at heights up to 2900 mm.

Performance

-

Intruder resistance

-

Minimum requirement

Not required.

To PAS 24.

Frame

-

Material

1.6 mm-thick Magnelis steel.

Threshold

15 mm rebated.

Guidance for specification option:

As standard.

Driveable.

Finish

-

Coating

Wood grain.

PVC laminate.

Stainless steel.

Polyester powder-coating.

Texture

Smooth.

Guidance for specification option:

All coatings except wood grain.

Wood grain.

Guidance for specification option:

Wood grain coating only.

Colour

Bespoke.

Guidance for specification option:

Insert requirements:

  • Polyester powder-coating available in 500 RAL and BS colours.
  • For PVC laminate or wood grain, consult manufacturer for details.
  • Not available for stainless steel coating.

Stainless steel.

Guidance for specification option:

Standard for stainless steel coating only.

Door leaf

-

Thickness

50 mm.

Core

Solid timber with integral steel stiffeners.

Panel details

Solid.

Material

Steel.

Finish

-

Coating

Wood grain.

PVC laminate.

Stainless steel.

Polyester powder-coated.

Texture

Smooth.

Guidance for specification option:

Polyester powder-coated, PVC laminate or stainless steel coatings.

Wood grain.

Guidance for specification option:

Wood grain coating only.

External colour

Bespoke.

Guidance for specification option:

Insert requirements:

  • Polyester powder-coating available in 500 RAL and BS colours.
  • For PVC laminate or wood grain, consult manufacturer for details.
  • Not available for stainless steel coating.

Stainless steel.

Guidance for specification option:

Standard for stainless steel coating only.

Internal colour

As External.

Bespoke.

Guidance for specification option:

Insert requirements:

  • Polyester powder-coating available in 500 RAL and BS colours.
  • For PVC laminate or wood grain, consult manufacturer for details.
  • Not available for stainless steel coating.

Stainless steel.

Guidance for specification option:

Standard for stainless steel coating only.

Hardware

Dog bolts and anti-jemmy astragal.

Guidance for specification option:

As standard.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Steel

Guidance for specification option:

1.6 mm-thick Zintec/ Aluzinc steel.

Laminate

Stainless steel

Recyclability

95

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

17 %

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Third party certifications

ADSA

ADSA Membership

Alcumus SafeContractor

Alcumus Safe Contractor Certificate of Accreditation

Made in Britain

Builders Profile Membership

CHAS

CHAS Certificate of Accreditation

Constructionline

Construction Line Gold Membership

dhf certificate

DHF Full Member

Made in Britain

Environment Agency Waste Management Certificate

Alcumus SafeContractor

SAFE PQQ Alcumus Safe Contractor

ISO 9001 Quality Management

ISO 9001

Literature

Steel Doors

Steel Doors

Acclaim Certificate of Health & Safety Accreditation

Acclaim Certificate of Health & Safety Accreditation

Avetta Consortium Membership

Avetta Consortium Membership

Citation Health & Safety Management Systems

Citation Health & Safety Management Systems

Cyber Essentials Certificate of Assurance

Cyber Essentials Certificate of Assurance

Employers Liability Insurance

Employers Liability Insurance
