BioPod® - IPS Unit

Verified by manufacturer today

BioClad

Anti-microbial modular IPS unit containing BioCote® technology.

Jump to:
BOS
01423 647055 Website

Application

Suitable Applications:

Designed for use in environments requiring stringent hygiene control, including:

  • Healthcare facilities
  • Mental health units
  • Care homes
  • Food manufacturing areas
  • Commercial kitchens
  • Pharmaceutical facilities
  • Laboratories
  • Washrooms (WCs)
  • Wet rooms

General information

Color

White

Beige

Black

Blue

Brown

Show more

Finish

Satin

Material

PVC

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

20 year

Uniclass

Ss_25_25_45_25 Duct and wall panel lining systemsPrimary

CAWS

K13/160 Proprietary

N13/30 Washbasins

N13/335 Washbasins

SKU Code

Biopod

Specification data - Duct and wall panel lining systems

Classification data

System performance

Fire performance of wall lining system to BS 476.

Pre-plumbed and prefixed sanitary appliances and fittings

Pre-cut sanitary outlet.

Guidance for specification option:

Predrilled to suit sanitary ware specifi cation.

Panels

PVC rigid sheet.

Fasteners

Self-drilling screws.
Adhesive.

System accessories

Plinth.

Execution

Bespoke.

Guidance for specification option:

Custom-made.

Pre-formed.

Guidance for specification option:

Pre-formed internal/external radius corners.

Predrilled.

Guidance for specification option:

Predrilled to suit a sanitary ware specification.

Colour

Satin White, LRV 88.
Oyster, LRV 71.
Green, LRV 75.
Cream, LRV 71.
Mint, LRV 60.
Blue, LRV 64.
Grey, LRV 57.
Linen, LRV 83.
Cesco, LRV 72.
Seafoam, LRV 81.
Fawn, LRV 39.
Verona, LRV 68.
Cloud, LRV 53.
Malva, LRV 68.
Vivid Purple, LRV 4.
Vivid Pink, LRV 17.
Vivid Red, LRV 7.
Vivid Orange, LRV 17.
Vivid Olive, LRV 37.
Vivid Green, LRV 47.
Vivid Blue, LRV 29.
Vivid Black, LRV 1.
Vivid Lime, LRV 59.
Vivid White, LRV 88.
Vivid Royal, LRV 15.
Vivid Steel, LRV 10.
Vivid Yellow, LRV 51.
Vivid Aqua, LRV 40.

Overall size

750 x 225 x 2.5 mm.

Guidance for specification option:

Manufactured to suit ceiling of maximum height 3000 mm.

Plinth

120 x 743 x 220 mm.

Guidance for specification option:

To receive coved vinyl flooring, including vinyl flooring.

Manufacturer guidance

Plinth size.

Maximum temperature

60°C.

Volatile organic compounds (VOC) content

0.

Waterproof covering

100%.

Corner treatments

Thermoformed.

Guidance for specification option:

Thermoformed external corners.

Samples required

Mock-up.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

PVC

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %
