Bespoke Overhead Sectional Garage Doors - Garage Door

Verified by manufacturer 5 months ago

Rundum Meir (UK) Ltd

Bespoke, ceiling mounted, overhead sectional garage door available in a wide variety of materials including many different timbers, high strength extruded aluminium steel and glass.

Jump to:
+44 (0)151 280 6626 Website

Application

  • Designed for use on high-end residential or commercial properties, within new-build, renovation or refurbishment projects for both traditional and contemporary property types.
  • For areas where garage floor space is minimal.

Description

Bespoke, ceiling mounted, overhead sectional garage door which moves up and down the side guides and is stowed under the ceiling or roof space when open, with torsion springs counterbalancing the door to ensure quiet and smooth operation.


Features and benefits:

  • Designed bespoke to fit most openings.
  • Available in a wide range of design options (e.g. the integration of individual panel patterns and designs including slat bevels and glazing) which can complement various architectural styles.
  • Cassettes provide clean horizontal sightlines.
  • Durable, with a high tensile strength.
  • Can be seamlessly integrated into most projects.
  • Features a ceiling mounted door mechanism which slides upwards with a smooth action.
  • Finger safety guards are incorporated between the panels for safety.
  • Manual as standard, with automation available if required, which is suitable for integration into all popular smart home automation systems.
  • Allows the garage door to follow the angle of the roof internally if required to maintain usable space inside garages with pitched roofs.
  • Conforms to BS EN 13241: Part 1.

General information

Color

Beige

Black

Blue

Bronze

Brown

Show more

Finish

Bright

Brushed

Buffed

Copper

Etched

Show more

Material

Aluminium

Guidance for specification option:

Consult manufacturer for details and insert requirements.

Glass

Guidance for specification option:

Consult manufacturer for details and insert requirements.

Bronze

Composite

Copper

Show more

Shape

Rectangle

Square

Crescent

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_30_59_24_75 Sectional overhead doorsetsPrimary

CAWS

L20/615 Sectional overhead doors

Specification data - Sectional overhead doorsets

Door panels

-

Type

Aluminium.

Guidance for specification option:

Consult manufacturer for details and insert requirements.


Double-skinned, insulated steel panel.

Guidance for specification option:

Consult manufacturer for details and insert requirements.


Glass.

Guidance for specification option:

Consult manufacturer for details and insert requirements.


Timber (Hemlock).

Timber (Larch).

Timber (Nordic Spruce).

Timber (Oak).

Timber (Sapele).

Timber (Superior Spruce).

Accessories

Not required.

Automation (belt drive operator).

Guidance for specification option:

Various versions are available, consult manufacturer for details.


Vision panels.

Type

Hi-lift.

Guidance for specification option:

Headroom of 600 mm or more.


Standard.

Guidance for specification option:

Internal headroom: 250 mm; side room: 120 mm (each side).


Trendline.

Guidance for specification option:

Internal headroom: 200 mm; low headroom: 120 mm; side room: 100 mm (each side).


Vertical lift.

Guidance for specification option:

Side room: 170 mm (each side). For tall garages only, consult manufacturer for details.


Roof

Follow roof line.

Guidance for specification option:

Insert angle requirement.


Standard.

Guidance for specification option:

See manufacturer's literature for drawing reference.


Lintel fascia

Required.

Not required.

Sustainability data

Country of material origin

-

Manufacturer guidance

Depends on the material chosen for the garage door (e.g. wood, aluminium, glass).

Country of product manufacture

Germany

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

-

Manufacturer guidance

Depends on the material chosen for the garage door (e.g. wood, aluminium, glass).

Recyclability

-

Manufacturer guidance

Depends on the material chosen for the garage door (e.g. wood, aluminium, glass).

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

-

Manufacturer guidance

Depends on the material chosen for the garage door (e.g. wood, aluminium, glass).

Literature

Rundum Meir Garage Door Brochure

Rundum Meir Garage Door Brochure

Garage door images

Garage door images
