BASF Elastospray® 1623-14-45
Application

The system was particularly formulated to be used in applications with a high requirement for compression resistance (floors, terraces, roofs, etc).

Suitable substrates include:

  • Concrete.
  • Brick.
  • Wood.
  • Steel.

Description

The Elastospray 1623/14/45 system has been developed as a sprayed (in-situ) polyurethane (PU) thermal insulation.

Features and benefits:

  • Excellent properties as an insulation material.
  • Excellent compression strength values.
  • Suitable for insulating large areas, including irregularly shaped surfaces such as undulated roofs.
  • Reaction to fire (to EN 13501-1): Class E.
  • Good values of compressive creep.
  • Excellent adhesion to the substrate. The spray foam bonds to most surfaces without the need for glues or mechanical fasteners.
  • Does not contain hydrochlorofluorocarbons (HCFCs).
  • CE marked, and manufactured in accordance with EN 14315-1: 2013.

Applications:

The system was particularly formulated to be used in applications with a high requirement for compression resistance (floors, terraces, roofs, etc).

Suitable substrates include:

  • Concrete.
  • Brick.
  • Wood.
  • Steel.

General information

Material

Polyurethane spray foam, including a mixture of polyols and additives (component A), and methylene diphenylmethane diisocyanate (MDI, component B)

Uniclass 2015

Pr_25_31_28_65 Polyisocyanurate (PIR) foam insulationPrimary

CAWS

J31/120 Warm deck roof coating

P10/147 Polyurethane foam sprayed between rafters

P10/185 Soffit insulation

P10/205 Insulation sprayed between studs

Specification data - Polyisocyanurate (PIR) foam insulation

Product Reference

BASF Elastospray® 1623-14-45

Thickness

See 'Options' below and insert requirements.

Standard product features

Material:

Polyurethane spray foam, including a mixture of polyols and additives (component A), and methylene diphenylmethane diisocyanate (MDI, component B).

Technical characteristics:

  • Viscosity (at 25°C): Component A: 225 mPa/s; component B: 220 mPa/s.
  • Density (at 25°C): Component A: 1.18 g/cm³; component B: 1.23 g/cm³.
  • Cream time: 4 s.
  • Gel time: 7 s.
  • Tack free time: 8 s.
  • Breaker free rise density (FRB): 37 kg/m³.
  • Mixing ratio: 1:1 (volume).
  • Application/ substrate temperature: 5–40°C.
  • Relative humidity: <85%.
  • Substrate moisture content: ≤20%.
  • Short term water absorption by partial immersion: <0.20 kg/m².
  • Water permeability (expressed as short-term water absorption by partial immersion): 0.20 kg/m².
  • Water vapour resistance factor: ≥80 m.
  • Closed cell content: ≥90%.
  • Compressive strength (10% deformation) ≥300 kPa.
  • Compressive stress: 90 kPa.
  • Compressive creep: ≤2.5%.
  • Total reduction thickness: ≤3.0%.
  • Extrapolation: 10 years.
  • Thermal conductivity at 10°C: Consult performance chart related to different thicknesses.

Product Options

Thickness:

Dependent on application, consult the manufacturer for information. The thickness of each applied layer should be between 1–4 cm. In order to maintain adequate dimensional stability, it is not recommended to apply thicker layers. See manufacturer's literature for performance charts related to different thicknesses.
