Base Unit with Storage Trays
Verified by manufacturer 1 month ago
Healthcare, single unit (HL/BTS) - 360 mm wide
Healthcare, single unit (HL/BTS) - 360 mm wide
CHAS
Certificate type
Constructionline
Certificate type
A range of base units with storage trays, suitable for healthcare or education applications.
Application
Suitable for healthcare, education, veterinary, MOD, prison and dental applications.
Description
A range of base units with storage trays, suitable for healthcare or education applications.
Features and benefits:
- Compatible with other products in the David Bailey Healthcare or education furniture ranges.
- Available in a wide range of colours.
General information
Color | Beige Black Blue Brown Cream |
Finish | Laminated |
Material | Medium density fibreboard (MDF) Chipboard Laminate Polypropylene |
Shape | Rectangle |
Length | 360 mm 720 mm 1080 mm |
Width | 565 mm |
Height | 860 mm |
Warranty description | Five year |
Uniclass | |
CAWS | N11/310 Fitted base units N10/130 Laboratory furniture N10/135 Storage and display units |
Specification data - Laboratory storage units
Form | Floor-mounted open cupboard units. |
Dimensions | 360 x 565 x 860 mm.360 x 565 x 700 mm.Manufacturer guidance(w x d x h). Height including plinth. |
Material | Carcass: 18 mm Melamine-faced particleboard, 12 mm MFC backs. |
Finish | High-pressure laminate (HPL). |
Colour | Manufacturer guidanceA selection of 60 laminate colours are available from Polyrey and Pfleiderer. Consult manufacturer's literature and insert requirements. |
Integral accessories | 6 no. Gratnell polypropylene trays. |
Plinth | Not required. 18 mm black melamine faced MDF board fixed via clips to adjustable feet. |
Accessories | Not required. Infill panel - specified separately. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Medium density fibreboard (MDF) Chipboard Laminate Polypropylene |
Recyclability | Non-reusable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 30 % |
Expected Life | 30 year |
Third party certifications
Literature
DBFS Healthline Healthcare Furniture
DBFS Education Furniture
Merino Laminate Colour Chart
Polyrey Laminate Colour Chart
Polyrey Laminate Pattern Colour Chart
Case studies
UCL Hospitals
